PKT-23K

Pocket-Sized UHF FM Portable Radio

High Function Transceiver that Advances your Business

Kenwood PKT-23K UHF Two-Way Radio - At only 3.9oz, this 1.5 Watt, 4 Channel –

Built-in 1,430 mAh Li-Ion battery provides Up to 15 hours of operation (5-5-90;

battery saver ON) – PKT-23K meets or exceeds MIL-Spec Standards established by

the U.S. Department Of Defense – 3.5mm audio jack – Micro USB connector

for programming.

GENERAL FEATURES

•1.5 Watts Transmit Power

•4 Channels

•39-QT/168-DQT Coded Squelch

•Super Lock (Manager Key Lock)

•Scan Function

•4 PF Keys

•Enhanced Kenwood Audio

•VOX Ready

•Voice Announcement

•Tone Alert

•3 Levels Battery Indicator

•IP54 & MIL-STD 810 C/D/E/F/G 11 items

•Busy Channel Lockout

•Battery Saver

•Time out Timer

•Monitor

•Wireless Clone

ACCESSORIES INCLUDED

•KNB-71L 1,430mAh Li-Ion

•KSC-44 2.5-Hour Fast Charger

& Power Supply

•KBH-20 Belt Clip

•Owner’s Manual

•2-year Warranty Card

Actual Size

Operating Conditions

Open areas without

obstructions

Up to 5 miles (8 km)

Residential areas

(near buildings)

Up to 1.5 miles (2.4 km)

In steel and/or concrete

reinfoced buildings

Up to 225,000 sq.ft

(20,900 sq.m)

In high-rise buildings Up to 17 floors

Note:

Talk range will vary based on terrain and

conditions.

Options

ADS#23813 Printed in USA

Specifications shown are typical.

Specifications are subject to change without notice, due to advancements in technology.

ProTalk®is a registered trademark of JVCKENWOOD Corporation in the

United States and other countries.

Model PKT-23K

GENERAL

Frequency Range 460-470 mHz

BRS Preset 99 Channels

Number of Channels 4

Channel Spacing

(FCC Narow Compliant) 12.5 kHz

Channel Step 5, 6.25 kHz

Operating Voltage 3.8V DC±10%

Battery Life (5-5-90 duty cycle)

with KNB-71L (1,430mAh) Approx. 11 hours (Battery saver off)

Approx. 15 hours (Battery saver on)

Operating Temperature Range* -14°F ~ +140°F (-10°C ~ +60°C)

Frequency Stability ±2.5ppm (-14°F ~ +140°F)

Antenna Impedance 50 Ω

Dimensions (W x H x D), Projections not Included

Radio with KNB-71L 1.8 x 3.3 x 0.8 in. (45.7 x 83.8 x 20.3 mm)

Weight (net)

Radio with KNB-71L 3.9 oz. (110 g )

FCC ID Pending

FCC Compliance Part 90

Model PKT-23K

RECEIVER (Measurements made per TIA/EIA-603)

Sensitivity (12dB SINAD)

Narrow 0.22 µV

Selectivity

Narrow 60 dB

Intermodulation Distortion

Narrow 50 dB

Audio Output 300 mW with less than 5% distortion

TRANSMITTER (Measurements made per TIA/EIA-603)

RF Output Power

High 1.5 W (ERP)

Low 0.5 W (ERP)

S purious Response 55 dB

Modulation

Narrow 11KØF3E

FM HUM & Noise

Narrow 50 dB

Audio Distortion Less than 5%

Specifications

All accessories and options may not be available in all markets.

Contact an authorized Kenwood dealer for details and complete list of all accessories and options.

Applicable MIL-STD & IP

Standard MIL 810C MIL 810D MIL 810E MIL 810F MIL 810G

Methods/Procedures Methods/Procedures Methods/Procedures Methods/Procedures Methods/Procedures

Low Pressure 500.1/Procedure I 500.2/Procedure I, II 500.3/Procedure I, II 500.4/Procedure I, II 500.5/Procedure I, II

High Temperature 501.1/Procedure I, II 501.2/Procedure I, II 501.3/Procedure I, II 501.4/Procedure I, II 501.5/Procedure I, II

Low Temperature 502.1/Procedure I 502.2/Procedure I, II 502.3/Procedure I, II 502.4/Procedure I, II 502.5/Procedure I, II

Temperature Shock 503.1/Procedure I 503.2/Procedure I 503.3/Procedure I 503.4/Procedure I, II 503.5/Procedure I

Solar Radiation 505.1/Procedure I 505.2/Procedure I 505.3/Procedure I 505.4/Procedure I 505.5/Procedure I

Rain 506.1/Procedure I, II 506.2/Procedure I, II 506.3/Procedure I, II 506.4/Procedure I, III 506.5/Procedure I, III

Humidity 507.1/Procedure I, II 507.2/Procedure II, III 507.3/Procedure II, III 507.4 507.5/Procedure II

Salt Fog 509.1/Procedure I 509.2/Procedure I 509.3/Procedure I 509.4 509.5

Dust 510.1/Procedure I 510.2/Procedure I 510.3/Procedure I 510.4/Procedure I, III 510.5/Procedure I

Vibration 514.2/Procedure VIII, X 514.3/Procedure I 514.4/Procedure I 514.5/Procedure I 514.6/Procedure I

Shock 516.2/Procedure I, II, V 516.3/Procedure I, IV 516.4/Procedure I, IV 516.5/Procedure I, IV 516.6/Procedure I, IV

International Protection Standard

Dust & Water Protection IP54

■KNB-71L

Li-Ion Battery

(1,430 mAh)

■ KSC-44

Fast Charger

for the PKT-23K

■ KSC-446

Six Unit Fast Charger

For PKT-23K

■ KHS-33

Earbud In-line

PTT Headset

(Single Pin Jack)

■ KHS-34

C-Ring In-line

PTT Headset

(Single Pin Jack)

■KBH-20

Spring Action Belt Clip
