Sida 1/3
KERN FCB 15K-3DM
The new FCB: Checkweighing and portioning scale with up to three interfaces, with optional verification
1
Category
Brand KERN
Product categoriy Industrial scale
Product group Bench scale
Product family FCB
Measuring System
Construction type of the scale Multi-division balance
Weighing system Strain gauge
Weighing capacity [Max] 6 kg; 15 kg
Readability [d] 0,002 kg; 0,005 kg
Reproducibility 0,002 kg; 0,005 kg
Linearity ± 0,002 kg; 0,005 kg
Minimum weight [Min] 0,04 kg
Resolution 3.000, 3.000
Tare range 15 kg
Adjustment options
Adjusting with external
weight
Recommended adjusting weight 15 kg (F2)
Possible calibration points 5 kg; 10 kg; 15 kg
Stabilization time 2 s
Warm-up time 10 min; 10 min
Eccentric loading at 1/3 [Max] 0,002 kg; 0,005 kg
Default unit kg
Units
kg
g
gn
dwt
ozt
ct
lb
oz
ffa
PCS
%
Units (if device is conformity
assessed)
kg
g
Conformity assessment possible ✓
Loadcell type
aluminium IP65 silicone-
coated
Display
Display type LCD
Display backlight ✓
Display screen size 120×38 mm
Display digit height 25 mm
Languages of the user interface
English
Symbol language
Construction
Dimension housing (W×D×H) 322×267×91 mm
Dimensions completely mounted
(W×D×H)
325×270×105 mm
Dimensions weighing surface
(W×D)
252×225 mm
Dimensions weighing surface 252×225 mm
Material housing plastic
Material weighing plate stainless steel
Material display housing Plastics
Material load cell(s) aluminium
Level indicator ✓
Levelling feet adjustable ✓
Transport safety lock - bolt torque 0,4 Nm
Functions
Sum memory function ✓
Recipe/summing level Sum A
Percentage determination ✓
Conversion function ✓
Tolerance weighing ✓
Tolerance weighing - type of signal
acoustically
visual
Underfloor weighing None
Alibi memory internal memory
Alibi memory - number of memory
spaces
250.000
Standby function ✓
Counting function ✓
Counting resolution (laboratory
conditions)
30.000
Counting reference weight can be
entered
✓
KERN FCB 15K-3DM
The new FCB: Checkweighing and portioning scale with up to three interfaces, with optional verification
2
Smallest piece weight when piece
counting - laboratory conditions
500 mg
Smallest piece weight when piece
counting - normal conditions
5 g
Reference quantity 5, 10, 20, 50, free, Input
IP protection - complete device -
IP protection - display no IP protection
IP protection - load cell IP65
Memory - total size 0,016 GB
Auto-off interval(s) in battery
mode/rechargeable battery mode
2 min
1 min
30 min
60 min
30 sec
Tare function manual (multi)
Number of keys for operation 6
Interface
Interfaces
RS-232 (optional)
Ethernet (optional)
Alibi memory
Bluetooth BLE (v4.0)
(optional)
USB-Device (optional)
KUP
WiFi (optional)
EasyTouch (ET) - Compatibility vollständig
EasyTouch (ET) - Connection type KUP
Power Supply
Supplied power supply Power supply unit
Plug-in power supply type Power adapter
Plug-in power supply / adapter for
countries - included with the
delivery
EURO
UK
US
CH
Plug-in power supply / adapter for
countries - optional
EURO
UK
US
CH
Input voltage power supply /
power [Max]
100 V - 240 V AC, 50 /
60 Hz
Input voltage device / power [Max] 5,9V, 1A
Battery / accumulator type Li-Ion
Battery operating time 20 h
Rechargeable battery operating
time - backlight on
24 h
Rechargeable battery operating
time - backlight off
48 h
Rechargeable battery charging
time
8 h
Rechargeable battery optional Rchrg. battery optional
Environmental conditions
Ambient temperature [Min] -10 °C
Ambient temperature [Max] 40 °C
Humity of environment [Min] 0 %
Humity of environment [Max] 80 %
Storage temperature [Min] -20 °C
Storage temperature [Max] 60 °C
Approval
CE mark ✓
Conformity assessment possible
ex works
✓
Accuracy classe III
Verification scale interval [e] 0,002 kg; 0,005 kg
Services (optional)
Article number for adjustment at
the location of installation
961-248
Article number for conformity
assessment
965-228
Article number for DAkkS
calibration
963-128
Article number for certificate of
conformity (verification)
969-517
Packing & Shipping
Delivery time 1 d
Dimensions packaging (W×D×H) 395×335×200 mm
Net weight 3,63 kg
Shipping method Parcel service
Net weight approx. 3,8 kg
Gross weight approx. 4,6 kg
Shipping weight 5,3 kg
KERN FCB 15K-3DM
The new FCB: Checkweighing and portioning scale with up to three interfaces, with optional verification
3
Pictograms
STANDARD
OPTION
FACTORY
