Sida 1/4

K O N F T E L . C O M

Konftel is a leading company within collaboration endpoint solutions.

Since 1988, our mission has been to help people in businesses around the

world to have meetings regardless of distance. Based on our success,

we know that remote collaboration is a smooth way to save time,

money and at the same time contribute to a more sustainable world.

Crystal clear audio and a sharp video image are essential for efficient meetings,

this is why we only focus on cutting-edge technology in our Collaboration Solutions.

Our audio technology OmniSound

is built into all Konftel Conference

phones and devices. The products are sold globally under the Konftel brand

and our headquarter is based in Sweden.

Read more about the company and our products at konftel.com.

Konftel AB, Box 268, SE-901 06 Umeå, Sweden

Tel: E-mail: +46 90 70 64 89 info@konftel.com

K O N F T E L . C O M

Good goods!

Konftel is a Climate Neutral certified company. We have measured and offset our

entire footprint of greenhouse gases, and are committed to reduce our emissions.

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

HOW IT WORKS

WHAT YOU NEED

Laptop with the

collaboration app

Konftel OCC

USB cable

2. Connect the USB cable

and wait until configuration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Konftel C50800 Hybrid

and C20800 Hybrid

I N S T A L L A T I O N G U I D E

Installation guide

Konftel 800 Hybrid video kit

900103312

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

Connect to PoE

Connect the network cable to an existing network

with PoE support or use the supplied PoE Injector kit.

HOW IT WORKS

WHAT YOU NEED

2. Connect the USB cable

and wait until configuration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

INSTALL ATION

After installation, tear off next page and place it on the table next to the orange cable.

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Connect the

HDMI cable to

the laptop if

you can’t run

DisplayLink.

Laptop with the

collaboration app

Konftel OCC

USB cable

PACKING LIST

Konftel 800

• USB cable (to be replaced by

)

• Network cable

• Get started guide

• Safety declaration

Konftel PoE-Injector kit

• Power cable

• Network cable

• Safety declaration

Konftel OCC Hub

• USB cable

(Konftel 800/Konftel Ego)

• USB cable

(Konftel 55/300-series)

• USB cable

(laptop)

• AC adapter

• Velcro

• Quick guide and Safety declaration

910101088

900102149

900102150 / 902102150

903102150 / 804102150

1. CAMERA

4. HUB

2. AUDIO 3. POE INJECTOR

Konftel Cam50

• USB cable

• AC adapter

• Remote control with two AAA

batteries

• Wall mount

• Quick guide and Safety declaration

931401002 / 932401002

933401002 / 834401002

HDMI cable

(not included)

Konftel Cam20

• USB cable

• Remote control with two

AAA batteries

• Quick guide and Safety declaration

931201001

One of the following cameras is included in this video kit.

Produktspecifikationer

Varumärke:	KONFTEL
Kategori:	Videokonferenssystem
Modell:	C20800 Hybrid
Produkttyp:	Videokonferenssystem för grupper
Inbyggd display:	Ja
Vikt:	2800 g
Höjd:	220 mm
Förpackningens bredd:	395 mm
Skärm diagonal:	4.3 "
Upplösning:	480 x 800 pixlar
Pekskärm:	Ja
Bluetooth-version:	4.1
Videoformat som stöds:	H.264, MJPG, YUY2
Videolägen som stöds:	2160p
Maximal bildfrekvens:	30 fps
Snabbstartsguide:	Ja
Certifiering:	EMC: 2014/30/EU, EMC Regulations 2016, LVD: 2014/35/EU, Electrical Equipment (Safety) Regulations 2016, WEEE: 2012/19/EC, RoHS: 2011/65/EU, REACH: EC 1907/2006
Bildsensorstorlek:	- "
Digital zoom:	8 x
Maximal videoupplösning:	- pixlar
Grafikupplösningar som stöds:	3840 x 2160
USB-anslutning:	USB Typ B
Antal mikrofoner:	3
röstigenkänning:	G.711, G.722, G.729, iLBC
Antal personer:	- personer
Fjärrkontroll ingår:	Ja
Utgångsnivå:	0/95 dB
Högtalarens vikt:	1400 g
Produktens färg:	Svart
bruksanvisning:	Ja
HD-typ:	4K Ultra HD
Låddjup:	480 mm
Vikt inkl. förpackning:	3840 g
Windows-operativsystem som stöds:	Windows 10 Education, Windows 7, Windows 8
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	5 - 40 ° C
Intervall för relativ operativ luftfuktighet:	20 - 80 %
Hållbarhetscertifiering:	Low Voltage Directive (LVD), REACH, RoHS, WEEE
AC-inspänning:	100 - 240 V
Kabel inkluderad:	AC, LAN (RJ-45), USB Type-A to USB Type-B
OSD-språk:	DAN, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POR, SWE
Frekvensområde:	100 - 20000 hz
Ljuddämpning:	Ja
Nätverksansluten (Ethernet):	Ja
AC-adapter inkluderad:	Ja
Ström:	4 A
Nätverkskabelns längd:	6.5 m
Upplösning vid filmning:	3840x2160@30fps
Bluetooth:	Ja
Kommunikationsstandarder:	IEEE 802.3af, IEEE 802.3at
Harmonized System (HS)-kod:	85176990
Synfältsvinkel (FOV):	123 °
Produktvikt (oz):	Ja
Typ av kabellåsanslutning:	Kensington
Power over Ethernet (PoE)-portar kvantitet:	1
Kamera inkluderad:	Ja
Megapixel:	- MP
Justering av fokus:	Automatisk
Ekodämpning:	Ja
Mikrofon, riktning:	Rundtagande
Diagonal synfält:	123 °
Likströmsdriftspänning:	5 V
Upptagningsområde för mikrofon:	6 m
Högtalarens mått (B x D x H):	326 x 370 x 75 mm
