Sida 1/21

P/N: 2900-301225 Rev 1 www.KramerAV.com

USER MANUAL

MODELS:

FC-101Net

Dual Dante Interface Decoder

FC-102Net

Dual Dante Interface Encoder

Kramer Electronics Ltd.

FC-101Net, FC-102Net – Contents

Contents

Introduction 1

Getting Started 1

Overview 2

Typical Applications 3

Defining FC-101Net and FC-102Net Dual Dante Interface 4

Mounting FC-101Net / FC-102Net 6

Connecting the Devices 7

Connecting FC-101Net 7

Connecting FC-102Net 8

Connecting the FC-101Net Output to an Unbalanced Stereo Audio Acceptor 8

Connecting an Unbalanced Stereo Audio Source to the FC-102Net Input 9

Connecting to FC-101Net / FC-102Net via RS-232 9

Setting FC-102Net DIP-switches 10

Upgrading the Firmware 11

Technical Specifications 12

Default Communication Parameters 13

Protocol 3000 14

Understanding Protocol 3000 14

Protocol 3000 Commands 15

Result and Error Codes 17

Kramer Electronics Ltd.

FC-101Net, FC-102Net – Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

• Review the contents of this user manual.

Go to www.kramerav.com/downloads/FC-101Net or www.kramerav.com/downloads/FC-

102Net to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

Achieving the Best Performance

• Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

• Do not secure the cables in tight bundles or roll the slack into tight coils.

• Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

• Position your Kramer FC-101Net / FC-102Net away from moisture, excessive sunlight

and dust.

Safety Instructions

Caution:

• This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

• For products with relay terminals and GPI\O ports, please refer to the permitted rating

for an external connection, located next to the terminal or in the User Manual.

• There are no operator serviceable parts inside the unit.

Warning:

• Do not open the unit. High voltages can cause electrical shock! Servicing by qualified

personnel only.

Produktspecifikationer

Varumärke:	Kramer
Kategori:	Server
Modell:	FC-102Net
Vikt:	100 g
Bredd:	62.2 mm
Djup:	51.8 mm
Höjd:	24.4 mm
Förpackningens bredd:	157 mm
LED-indikatorer:	Ja
Maximal bildfrekvens:	- fps
Certifiering:	CE, RoHs, WEEE
Maximal videoupplösning:	- pixlar
Produktens färg:	Svart
Låddjup:	120 mm
Vikt inkl. förpackning:	200 g
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
PTZ-styrning:	Nej
I / O-terminalportar:	2
