Sida 1/27

P/N: 2900-301167 Rev 3 www.kramerAV.com

USER MANUAL

MODEL:

KDS-8, KDS-8F

SDVoE Streaming Transceivers

Kramer Electronics Ltd.

KDS-8 – Contents

Contents

Introduction 1

Getting Started 1

Overview 2

Defining KDS-8 SDVoE Streaming Transceiver 4

Mounting KDS-8 8

Connecting KDS-8 9

Connecting KDS-8F 10

Operating KDS-8 12

Changing Encoder/Decoder Mode – Front Panel 12

Configuring Settings – OSD 13

Technical Specifications 22

Kramer Electronics Ltd.

KDS-8 – Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

• Review the contents of this user manual.

Go to www.kramerav.com/downloads/KDS-8 to check for up-to-date user manuals,

application programs, and to check if firmware upgrades are available (where appropriate).

Achieving Best Performance

• Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

• Do not secure the cables in tight bundles or roll the slack into tight coils.

• Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

• Position your Kramer KDS-8 away from moisture, excessive sunlight and dust.

This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

Safety Instructions

Caution:

• This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

• For products with relay terminals and GPI\O ports, please refer to the permitted rating

for an external connection, located next to the terminal or in the User Manual.

• There are no operator serviceable parts inside the unit.

Warning:

• Use only the power cord that is supplied with the unit.

• To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which located on the bottom of the unit.

Produktspecifikationer

Varumärke:	Kramer
Kategori:	AV extender
Modell:	KDS-8
Vikt:	500 g
Bredd:	231 mm
Djup:	116 mm
Höjd:	25 mm
Förpackningens bredd:	351 mm
LED-indikatorer:	Power, Status
Videolägen som stöds:	2160p
Maximal upplösning:	3840 x 2160 pixlar
Ljudsystem:	Flerkanalig
HDCP:	Ja
Grafikupplösningar som stöds:	3840 x 2160
Färgdjup:	10 bit
Uteffekt:	3 A
Ljudutgångskanaler:	7.1 kanaler
Bandbredd:	10 Gbit/s
Maximal dataöverföringshastighet:	10000 Mbit/s
RJ-45 utgångsportar:	2
HDCP-version:	2.2
Antal HDMI-utgångar:	1
Driftspänning:	12 V
SFP transceiver typ:	Koppar
Produktens färg:	Svart
Låddjup:	212 mm
Vikt inkl. förpackning:	1200 g
Typ av ethernet-gränssnitt:	10 Gigabit Ethernet
Temperatur vid drift:	0 - 45 ° C
Temperaturintervall (förvaring):	-20 - 70 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Gränssnittstyp:	RJ-45
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Ja
Likströmsingång:	Ja
Maximal överföringshastighet avstånd:	100 m
Fjärrstyrd IR-utgång:	1
HDMI-in:	1
3,5 mm-utgång:	Ja
Fjärrstyrd (IR) ingång:	1
RS-232-ingångar:	1
Orörd överföring av HDCP:	Ja
IR-överföring:	Ja
Orörd överföring av RS-232:	Ja
