KDS-USB2 Quick Start

P/N:

2900-301391QS

Rev:

3

Scan for full manual

KDS-USB2 Kit/KDS-USB2-/KDS-USB2-DEC EN

Quick Start Guide

This guide helps you install and use your KDS-USB2 for the first time.

Go to www.kramerav.com/downloads/KDS-USB2 to download the latest user manual and check if firmware

upgrades are available.

Step 1: Check in the bwhat’sox

KDSKDS-USB2-EN and/or -USB2-DEC

1 Power adapter and cord (for ) KDS-USB2-DEC

1 Quick start guide

1 USB2 cable A male to B male (for ) KDS-USB2-EN

Step 2: Get to know your KDS-USB2

KDS-USB2-EN

#

Feature

Function

1

Power LED

Lights blue when power is supplied by USB connection. KDS-USB2-DEC

2

Link LED

Lights green when a USB link is established between the encoder and the decoder.

Flashes slowly when the unit attempts to establish a link. Flashes quickly when in pairing mode.

O when a link is not established.

3

Host LED

Lights green when is properly enumerated on the host computer. KDS-USB2

Flashes when in suspended state. a

4

Activity LED

Lights yellow when activity between the decoder and encoder/s is detected.

O when in suspended mode.

5

Cong Button

For factory use.

6

Mode Button

Use for with the decoder/ pairingKDS-USB2-ENKDS-USB2-DECs.

7

USB Host Port

Connect to the host computer.

8

LinkRJ-45 Connector

Connect to the . KDS-USB2-DEC

KDS-USB2-DEC

#

Feature

Function

9

USB Ports

Connect up to 4 USB type A devices.

10

Power LED

Lights blue when 24 V power is supplied.

11

Link LED

Lights green when a USB link is established between the encoder and the decoder.

Flashes slowly when the unit attempts to establish a link. Flashes quickly when in pairing mode.

O when a link is not established.
