P/N: 2900-300612 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
VM-400HDCPxl
1:4 DVI Distributor
Kramer Electronics Ltd.
VM-400HDCPxl Contents –
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Dening -400HDCPxl 1:4 DVI Distributor 4VM
Mounting VM-400HDCPxl 5
Connecting VM-400HDCPxl 6
Acquiring and Setting Current EDID 7
Forcing RGB Mode 8
Upgrading Firmware 9
Technical Specications 10
Default EDID 11
Protocol 3000 12
Understanding Protocol 3000 12
Protocol 3000 Commands 13
Result and Error Codes 15
Kramer Electronics Ltd.
VM-400HDCPxl Introduction –
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to www.kramerav.com/downloads/VM-400HDCPxl to check for up-to-date user manuals
application programs, and to check if rmware upgrades are available (where appropriate).
Achieving Best Performance
• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
• Position your Kramer away from moisture, excessive sunlight and dust.
VM-400HDCPxl
Safety Instructions
Caution:
• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• To ensure continuous risk protection, replace fuses only according to the rating
specied on the product label which located on the bottom of the unit.
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landll or incineration by requiring it to be collected
