Kramer Electronics, Ltd.

USER MANUAL







Model:

VP-210K

UXGA Line Amplifier

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 2

Overview 3

Your VP-210K UXGA Line Amplifier 4

Connecting the VP-210K UXGA Line Amplifier 5

Technical Specifications 6

Figures

Figure 1: VP-210K UXGA Line Amplifier 4

Figure 2: Connecting the VP-210K UXGA Line Amplifier 6

Tables

Table 1: VP-210K UXGA Line Amplifier Features 5

Table 2: Technical Specifications of the VP-210K UXGA Line Amplifier 6

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups

that are clearly

defined by function.

Thank you for purchasing your Kramer TOOLS VP-210K UXGA Line

Amplifier, which is ideal for:

 Dual monitor systems, local or remote (loop and output)

 Presentation systems for remote transmission and cable

equalization

The package includes the following items:

 VP-210K UXGA Line Amplifier

 Power adapter (5V DC input) and this user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high-performance high-resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Produktspecifikationer

Varumärke:	Kramer
Kategori:	mottagare
Modell:	VP-210K
Vikt:	250 g
Bredd:	123.8 mm
Djup:	22.2 mm
Höjd:	123.8 mm
Certifiering:	UL
VGA (D-Sub) ingångsportar:	1
Antal per paket:	1 stuk(s)
Kompatibla produkter:	6820, 6820EVS, 6808, 6700, 5820XL, 5820XL-EVS, 5808, 5700
Bandbredd:	350 MHz
VGA (D-Sub) utgångsportar:	1
K-faktor:	0.05 %
Signal/brusförhållande (SNR):	66 dB
Differentiell fas:	0.53 °
Differentiell förstärkning:	0.41 %
