Kramer Electronics, Ltd.
USER MANUAL
Models:
VP-2xl,
1:2 VGA Distributor
VP-6xl
N
,
1:6 UXGA Distributor
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
3
Overview 2
3.1
About the VP-2xl 2
3.2
About the VP-6xlN 2
4
Your Distributors 2
4.1
The VP-2xl 1:2 VGA Distributor 3
4.2
The VP-6xlN 1:6 UXGA Distributor 3
5
Installing on a Rack 6
6
Connecting the Distributors 7
6.1
Connecting the VP-2xl 7
6.2
Connecting the VP-6xlN 8
7
Technical Specifications 9
Figures
Figure 1: VP-2xl 1:2 VGA Distributor – Front and Rear View 3
Figure 2: VP-6xlN 1:6 UXGA Distributor – Front and Rear View 4
Figure 3: Underside of the VP-6xlN 1:6 UXGA Distributor 5
Figure 4: Connecting the VP-2xl 1:2 VGA Distributor 7
Figure 5: Connecting the VP-6xlN 1:6 UXGA Distributor 8
Tables
Table 1: Features and Functions of the VP-2xl 1:2 VGA Distributor 3
Table 2: Features and Functions of the VP-6xlN 1:6 UXGA Distributor 5
Table 3: Underside Features of the VP-6xlN 1:6 UXGA Distributor 5
Table 4: Technical Specifications of the VP-2xl 1:2 VGA Distributor 9
Table 5: Technical Specifications of the VP-6xlN 1:6 UXGA Distributor 9
Introduction
1
1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups
1
, which are clearly defined
by function.
Congratulations on purchasing your Kramer VP-2xl 1:2 VGA Distributor
and/or Kramer VP-6xl
N
1:6 UXGA Distributor.
This VP-2xl is ideal for:
Dual monitor desktop multimedia or teleconference systems
Presentation systems requiring a local monitor and projector operating
simultaneously
Schools, churches, A/V technicians, rental/staging
The VP-6xl
N
is ideal for:
Any professional system requiring high quality computer graphics (up to
at least UXGA) distribution to multiple monitors/projectors
Expanding and creating larger systems
The package includes the following items:
VP-2xl 1:2 VGA Distributor
2
or VP-6xl
N
1:6 UXGA Distributor
3
This user manual
4
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables
5
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 With a power adapter
3 With a power cord
4 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
5 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
