The Kramer Volume Control and Switch for Insert Plates
Congratulations on purchasing your Kramer W-LM which is ideal for the following
typical applications:
•Audio installations in hotels
•Presentation and training rooms
The Kramer W-LM is acombined volume control and pushpush-ON/- OFFswitch
module that fits a single slot ointo f any Kramer late, such as the ipnsert FLA-2F.
Figure 1 and Table 1 .definethe W-LM
Figure 1W- : LMFront and Rear
Table 1W- : LMFront and Rear Features
# FeatureFunction
1 Screw holesInsert module fixing screws
2 ON/OFF Switch and
Volume Knob
Push knob to toggle ON/OFF. Rotate knob clockwise to increase
volume, anti-clockwise to decrease volume
3 k Module Terminal BlocConnect to the cabling(see Figure 2and Table 2)
To install the W-LM:
1. Connect the cabling to the removable portion of the terminal blockpaying attention
to the wiring diagram shown in
Figure 2 and Table 2.
2. Plug the removable portionof the terminal block into the socket on the W-LM
module.
3. Insert the W-LMmodule in the required slot of the insert plate.
4. Insert the two screws to module in placesecure the and tighten thescrews.
Figure 2 shows the wiring connections of the W-LM.
Figure 2W- : LMWiring Connections
T2W- able : LMTerminal BlockWiring
# Function
1 Volume controlstart(CCW)
2 Volume control wiper
3 Volume control end (CW)
4
SPST switch
5
