WP-20CT EU PANEL SETQuick Start
P/N:
2900-301477QS
Rev:
1
Scan for full manual
WP-20CT EU PANEL SET Quick Start Guide
This guide helps you install and use your WP-20CT EU PANEL SETfor the first time.
Go to www.kramerav.com/downloads/WP-20CT EU PANEL SET to download the latest user manual and
check if rmware upgrades are available.
Step 1: Check in the b what’sox
1 faceplate
1 UK frame
1 EU frame
1 Quick start guide
Step 2: Install the -20CT EU PANEL SET WP
After mounting the device (see www.kramerav.com/downloads/WP-20CT EU PANEL SET) attach the frame to the device and
then click in the faceplate as shown in the illustration below:
European Version
We recommend that you use any of the following standard 1 Gang in-wall junction boxes (or their equivalent):
•: 1 Gang in-wall junction box, with a cut-hole diameter of mm and depth that can t in both the device and the EU68
connected cables (DIN 49073).
•1 Gang in-wall junction box, 75x75mm (W, H), and depth that can t in both the device and the connected cables UK:
(BS 4662).
