UMAREX GmbH & Co. KG • Laserliner • Gut Nierhof 2 • 59757 Arnsberg • Germany • Tel. +49 2932 9004-0 • info@laserliner.com • www.laserliner.com

RangeXtender M 70

Laser receiver with GRX-Ready technology, millimetre

Laser receiver with GRX-Ready technology, millimetre

Laser receiver with GRX-Ready technology, millimetre

Laser receiver with GRX-Ready technology, millimetre Laser receiver with GRX-Ready technology, millimetre

display and large reception range

display and large reception range

display and large reception range

display and large reception rangedisplay and large reception range

This laser receiver facilitates very fast alignment work over close

and long ranges and is suitable for all green line lasers with

GRX-READY technology. It quickly detects pulsating, high-

frequency laser lines up to a maximum distance of 70 metres.

With the integrated horizontal and vertical vials, the receiver can

be precisely aligned before use to ensure maximum accuracy

when detecting the laser line. The arrow symbol and millimetre

display provide users with the exact height difference between

the laser beam and the marking level. The measured value can

be quickly and easily read from the large LC displays on both

sides of the receiver. The rear display allows the user to also

work opposite to the beam’s emission direction while still being

able to read the measured values. The adjustable sensitivity of

1, 2, or 5 millimetres makes it easily adjustable to any

application – from high-precision work to faster, slightly less

precise measurements.

TECHNICAL DATA

TECHNICAL DATA

TECHNICAL DATA

TECHNICAL DATATECHNICAL DATA

Laser Reception

Range

max. 70 m

Length of

Receiver Unit

70 mm

Power Supply4 x 1.5V LR03 (AAA)

Operating Timeapprox. 20 hours

Operating

Conditions

-10°C … 40°C, max. humidity 80%

rH, no condensation, max. working

altitude 4000 m above sea level

Storage

Conditions

-20°C … 70°C, max. humidity 80%

rH

Dimensions (W x

H x D)

75 mm x 155 mm x 30 mm x

(without holder)

Weight270 g (without accessories and

batteries)

•

•

•

•

For all green line lasers with GRX-Ready technology

Allows time-saving, close and long range alignment work

Millimetre display for quick and accurate reading of height

differences with respect to the laser level

Large reception range: Detects laser lines in a range of up to

70 m

Item No.

Item No.

Item No.

Item No.Item No.GTIN (EAN)

GTIN (EAN)

GTIN (EAN)

GTIN (EAN)GTIN (EAN)SU

SU

SU

SUSU033.80A40215637460641

SCOPE OF DELIVERY
