190
FLOOR SCRUBBER DRIERS
STANDARD EQUIPMENT
RIDE ON WITH SWEEPING AND SCRUBBING SYSTEM
Equipped with:
• Comfort Duotech it is a 3 in 1 machine: it sweeps, washes, and dries
• Ultra compact dimensions and great handling like a walk behind scrubber dryer, ideal for maintenance cleaning
• Complete right/left side brush (1060 mm working width)
• Great battery autonomy (up to 4h) thanks to the very low consumption of washing solution and tanks large capacity
• Very precise detergent dosing system, proportional to the water supply, which determines a reduced
number of stops and maximum use of the battery charge for the effective operation of the machine
• Ergonomic steering wheel of new conception with very small turning radius (860mm) which allows it to
rotate practically on itself both to the right and to the left
• Self-leveling central brush that allows perfect work even on uneven surfaces
• Forced air flows keep the solution always within the washing track patended
• Sweeping, up to 1060mm, thanks to large diameter and intelligent side brushes (Active) which retract
automatically both in the event of an impact and when cornering to allow the perfect collection of all the material.
• Up to 30 L solid debris tank
• Double floor drying process that allows the rear wheels to travel without slipping on wet surfaces.
• Green feature: very low water consumption
• Seat hight kit available
Comfort Duotech 65 CSComfort Duotech 85 CS
code0.061.00610.061.0062
power supply
24V24V
cleaning width with right side brush880 mm880 mm
cleaning width with two side brushes1060 mm1060 mm
scrubbing width/squeegeewidth650/670 mm850/900 mm
turningradius860 mm860 mm
cleanwatertankcapacity90 l/23,77 gal90 l/23,77 gal
dirtywatertankcapacity100 l/26,41 gal100 l/26,41 gal
chemicaltankcapacity3 l/0,79 gal3 l/0,79 gal
solid wastecontainercapacity23 l/6,07 gal30 l/7,92 gal
main brush sizeØ300 x L 650 mmØ300 x L 850 mm
main brush speed900 RPM/min900 RPM/min
main brush pressureadjustable from the control paneladjustable from the control panel
dimensions/weight140x78x130 cm/350 kg140x105x130 cm/374 kg
Comfort Duotech
NEW
•
0.961.1187 Main brush
PPL/Tynex Duotech 65
•
0.961.1188 Main brush
PPL/Tynex Duotech 85
•
2 x 0.961.1189 PPL
side brush dx/sx
•
0.961.1191 Front
squeegee blade Duotech 65
•
0.961.1190 Rear
squeegee blade Duotech 65
•
0.961.1193 Front
squeegee blade Duotech 85
LINATEX®/AIROFLEX
0.961.1192 Rear squeegee
blade Duotech 85 LINATEX
Produktspecifikationer
| Varumärke: | Lavor |
| Kategori: | Sopmaskin |
| Modell: | COMFORT DUOTECH |
