Sida 1/2
120
SPRAY EXTRACTION UNITS AND FOAM CLEANING DEVICE
CARPET CLEANERS
STANDARD EQUIPMENT
• 5.209.0021 Hose 2,5
• 6.205.0197
• 5.209.0205
• 6.402.0108
• 6.402.0109
• 2 x 5.211.0102
• 5.212.0141
• 3.754.0048
• 3.697.0072 LC prefoam
Equipped with:
• 2 high efficiency by-pass motors
• Suction system with by-pass cooling
• Stainless steel tank
• Detergent pump (48W – 1 l/m – 15 bar)
• Steel closing hooks
• Static electric shock inhibitor
• Fully removable tank
• 12 l. detergent tank
• Shock proof trolley
• Safety floating
• Washable cartridge filter
• 7,5 m power cable
• Traceless wheels
• Accessories Ø 40
• Equipped with connection for compressed air and pressure gauge with pressure
adjuster for foam cleaning.
Windy IE Foam
code 8.239.0017
voltage 220-240V ~ 50-60Hz
n°motors - power (max) 2 - 2000 (2400) W high efficiency motor
column depression 22 kPa/2200 mmH
2
O
air suction 130 l/s
total volume/dust/liquid 65 l./30 l./40 l.
dimension/weight 44x46x96 cm / 24 kg
Optional:
• 5.212.0022 - Paper collector filter set (10 pcs)
• 5.209.0177 - Cloth filter for fine dust
• 5.212.0093 - Nylon filter
• 0.110.0020 - Antifoam device
• 3.697.0036 - Anti-foaming for recovery tank
• 3.697.0058 - (4x5 Kg) Acid-based det. for toilets
• 3.697.0057 - (4x5 Kg) Alkaline-based det.
alimentary environments
• 3.697.0056 - (4x5 Kg) Det. for fabrics and
carpeting
Windy IE Foam
121
CARPET CLEANERS
SPRAY EXTRACTION UNITS AND FOAM CLEANING DEVICE
Thanks to the special brush the foam can be spread quickly and
easily on the car seats or mats and can be removed after few
seconds with the transparent nozzle. Being equipped with two
high depression vacuum motors, 90% of the foam is recovered
with the great advantage of a very fast drying (20 min.) and a
better cleaning performace.
Fields of applications
Washing of: car body and interiors, carpets, sofas, restrooms,
kitchens and wherever is necessary to wash and sanitize.
Users:
Car dealers, car washers, garages, car body shops, contractor
cleaners and any other user which is provided with a source of
compressed air; in the absence of a compressed air system, Windy
IE Foam can also be used in combination with a small 24 liters
compressor.
Windy IE Foam is an injection/extraction cleaning machine ide-
al for car cleaning, as it can be used with thick foam or liquid
detergent. Windy IE Foam is equipped with a connection for
compressed air with pressure regulator and an external tank of
12 liters capacity, which allows the detergent refilling without
opening the machine.
A compressor with the following technical data is required:
Pressure 6 bar, Delivery rate 250 lt/min.
Windy IE Foam is ideal for the pre-washing of the car body,
rims and engine. Using the lance with the 7 (2 x 3,5) meters
hose can be produced a thick foam that will stay on the dirty
components, giving more effectiveness to the detergent. Windy
IE Foam is also an excellent two motors wet & dry vacuum clea-
ner with 65 liters tank capacity.
