Sida 1/21
Installation Guide for the
DocCAM 20 HDBT
Ceiling-Mounted Document Camera
Document 411-0017-31 Rev E
May 2018
ii
Contents
Overview 1
What's in this Guide 1
Features 1
Unpacking the Camera 2
A Quick Look at the Camera 3
Features of Interest During Installation 4
Connector Panel 4
Features of Interest During Operation 5
Installing the Camera 6
Don’t Void Your Warranty! 6
Cabling Notes 6
Pre-Installation Functional Check 7
Basic Connection Diagram 7
Options for Power and Other Connections 8
About Installation Height and Viewing Area 9
Selecting the Installation Area 9
Things You Will Need for the Installation 10
Installing the Camera in a Suspended Tile Ceiling 10
Preparing the Tile Ceiling 10
Completing the Installation in a Tile Ceiling 11
Installing the Camera in a Hard Ceiling 11
Preparing the Hard Ceiling 11
Completing the Installation in a Hard Ceiling 12
Powering Up the Camera 13
Status Light 14
Next Steps 14
Compliance Statements and Declarations of Conformity 15
FCC Part 15 Compliance 15
ICES-003 Compliance 16
European Compliance 16
Warranty Information 17
Index 18
1
Overview
This guide describes installation and related information for the DocCAM 20 HDBTceiling-mounted
document camera:
n Camera only, worldwide – 999-9968-000
n Camera with OneLINK HDMI camera extension, North America – 999-9968-
200
n Camera with OneLINK HDMI camera extension, Europe/UK – 999-9968-201
n Camera with OneLINK Bridge A/V interface, North America – 999-9968-300
n Camera with OneLINK BridgeA/V interface, Europe/UK – 999-9968-301
What's in this Guide
This guide covers:
n Unpacking the camera
n Tips for a successful installation
n Information on mounting and connecting the camera
n Camera power-on
Complete product information is available in the Integrator's Complete Guide to the DocCAM 20 HDBT
Ceiling-Mounted Document Camera.
Download manuals, dimensional drawings, and other information from www.vaddio.com/support.
Features
n Exmor® 1/2.8 type, high-speed, low-noise image sensor for 2.38 megapixels total, full HD (native
1080p/60)
n 20x optical zoom with horizontal field of view from 60° (wide end) to 3.3° (tele end)
n Low-power laser pointer for centering
n Superior low-light performance (0.4 Lux)
n Web interface for remote administration and operation, integration-ready Telnet and serial RS-232
control, presenter-friendly IR remote control
n Use with a OneLINK device for power, video, and control:
o
OneLINKHDMI – uncompressed HDMI video, bidirectional RS-232 connectivity for camera control
via third-party equipment, passes IP stream from the camera
o
OneLINK Bridge – OneLINKHDMIcapabiliities plus uncompressed USB 3.0 streaming, HD-SDI
output, and audio routed up to the camera and injected into the IP stream
Camera assembly numbers 998-9968-001 and 998-9968-100:
Class 1 Laser Product (IEC 60825-1:2014)
Produit Laser de la Classe 1 (IEC 60825-1:2014)
Klass 1 Laserprodukt (IEC 60825-1:2014)
Camera assembly number 998-9968-000 only:
This product contains a Class 3 laser.
