Safety Instructions

Leica DISTO™ D3a BT 776750 gb

FIN

ROK

RUS

User Manual

English

Congratulations on the purchase of your

Leica DISTO™ D3a BT .

Carefully read the Safety Instruc-

tions and the User Manual before

using this product.

The person responsible for the instrument must

ensure that all users understand these directions and

adhere to them.

Contents

Safety Instructions .............................................1

Start-up................................................................ 6

Menu functions...................................................9

Operation...........................................................11

Measuring ..........................................................12

Functions ........................................................... 13

Working with BLUETOOTH® ............................19

Appendix............................................................20

Safety Instructions

Symbols used

The symbols used in the Safety Instructions have the

following meanings:



WARNING:

Indicates a potentially hazardous situation or

an unintended use which, if not avoided, will result in

death or serious injury.



CAUTION:

Indicates a potentially hazardous situation or

an unintended use which, if not avoided, may result

in minor injury and/or in appreciable material, finan-

cial and environmental damage.

)

Important paragraphs which must be adhered

to in practice as they enabled the product to be used

in a technically correct and efficient manner.

Use of the instrument

Permitted use

• Measuring distances

• Computing functions, e. g. areas and volumes

• Storing measurements (BLUETOOTH®)

•Measuring tilts

Safety Instructions

Leica DISTO™ D3a BT 776750 gb

FIN

ROK

RUS

Prohibited use

• Using the instrument without instruction

• Using outside the stated limits

• Deactivation of safety systems and removal of

explanatory and hazard labels

• Opening of the equipment by using tools (screw-

drivers, etc.), as far as not specifically permitted

for certain cases

• Carrying out modification or conversion of the

product

• Use after misappropriation

• Use of accessories from other manufacturers

without the express approval of Leica Geosys-

tems.

• Deliberate or irresponsible behaviour on scaf-

folding, when using ladders, when measuring

near machines which are running, or near parts of

machines or installations which are unprotected

• Aiming directly into the sun

• Deliberate dazzling of third parties; also in the

dark

• Inadequate safeguards at the surveying site (e.g.

when measuring on roads, construction sites, etc.)

Limits of use

)

See section “Technical Data“.

The Leica DISTO™ is designed for use in areas perma-

nently habitable by humans, do not use the product

in explosion hazardous areas or in aggressive envi-

ronments.

Areas of responsibility

Responsibilities of the manufacturer of the orig-

inal equipment Leica Geosystems AG, CH-9435

Heerbrugg (for short Leica Geosystems):

Leica Geosystems is responsible for supplying the

product, including the User Manual and original

accessories, in a completely safe condition. (addi-

tional language versions can be found at:

www.disto.com.

Responsibilities of the manufacturer of

non-Leica accessories:

)

The manufacturers of non-Leica accessories

for the Leica DISTO™ are responsible for developing,

implementing and communicating safety concepts for

their products. They are also responsible for the

effectiviness of these safety concepts in combination

with the Leica Geosystems equipment.

Responsibilities of the person in charge of

the instrument:



WARNING

The person responsible for the instrument

must ensure that the equipment is used in accor-

dance with the instructions. This person is also

accountable for the deployment of personnel and for

their training and for the safety of the equipment

when in use.

The person in charge of the instrument has the

following duties:
