Sida 1/11
LevelOne
User Manual
HVE-9005
HDMI over Cat.5 Extender Kit
Safety and Notice
The HVE- HDMI Extender over Cat.5 Extender Kit 9005 has been tested for
conformance to safety regulations and requirements, and has been certified for
international use. However, like all electronic equipments, the HVE-9005
should be used with care. Please read and follow the safety instructions to
protect yourself from possible injury and to minimize the risk of damage to the
unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this
manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of
this unit is on a stable surface.
● Use only the power adapter and power cords and connection cables
designed for this unit.
● not use liquid or aerosol cleaners to clean this unit. Always unplug the Do
power to the device before cleaning.
TABLE OF CONTENTS
INTRODUCTION ...................................................................................................... 1
FEATURES .............................................................................................................. 1
SPECIFICATIONS ................................................................................................... 2
PACKAGE CONTENTS ........................................................................................... 3
CONNECTION DIAGRAM 3.......................................................................................
PANEL DESCRIPTIONS .......................................................................................... 4
Transmitting unit HVE-9005T ►.................................................................... 4
Receiving unit ► HVE-9005R ....................................................................... 5
IR PASS-THROUGH ................................................................................................ 6
HDMI PIN DEFINITION ............................................................................................ 7
HARDWARE INSTALLATION .................................................................................. 7
NOTICE .................................................................................................................... 8
1
INTRODUCTION
The HVE-9005 HDMI Extender over Cat.5 Extender Kit boosts up your video/audio
transmission distance up to 60m (198ft) in HDTV 1080p with 48-bit color depth. HVE-9005 also
supports the most advanced 3D video format complaint with HDMI specification and therefore
guarantees the highest 3D video compatibility on the market. With only one cost effective
Cat.5/5e/6 cable, users can readily extend HDTV sources from DVD players, Blu-ray Disc player,
PS3, PC, and any other kinds of sources compliant with TMDS to distant display monitors
including HDMI or DVI enabled TV sets or LCD PC monitors. With the advanced design for the
latest HDMI technology, deep color video, DTS-HD or Dolby TrueHD audio, and HDCP supports
and compatibility are all further insured. This flexibility makes HDCP compliant DVD players or
PS3 transmit utmost high quality video and audio with a greater distance at the minimal cost,
when integrating several components apart. In addition, HVE-9005 is also equipped with
bi-directional IR pass-through path. These bonus features allow users to boost IR control
distance up to 60m (198 ft) and makes IR control possible through only single Cat.5/5e/6 cable
including HDMI signals.
The HVE-9005 includes two units: transmitting unit HVE-9005T and receiving unit
HVE-9005R. The transmitting unit is used to capture the input HDMI / DVI signals with IR control
packets and carry the signals via one cost effective Cat.5/5e/6 cable. The receiving unit is
responsible for equalizing the transmitted HDMI signal and reconstructing IR signals. HVE-9005
offers the most convenient solution for digital signage with long distance A/V transmission path,
and with 10G transmission width ready, HVE-9005 is ready for your next HDMI generation and
applications!
FEATURES
Support HDMI Deep Color & full 3D & 4K2K@30 (HDBaseT-Lite technology)
Extend the transmission up to 60m (198ft) from the HDMI source at Full HD 1080p 48-bit
and 40m (130ft) at 4K2K@30
HDCP & EDID Bypass CEC support Auto equalization , ,
Pure unaltered uncompressed 7.1ch digital HDMI over Cat.5/5e/6 cable transmission
DTS-HD Master Audio and Dolby TrueHD high bit rate audio support
Support full frequency IR signal from 20KHz to 60KHz
-directional IR path-through Bi
Wall mounting housing design for easy and robust installation
The length depends the characteriscs and quality the cables. Higher resoluons and on of
longer transmission distances require low skew cables ns/ for best performance. (<25 100m)
Unshielded CAT6 with metal connectors is recommended. RJ45
