Evaporative Humidifier
User Manual
2
Table of Contents
Package Contents
Specifications
Safety Information
Getting to Know Your
Smart Humidifier
Controls & Indicators
Getting Started
VeSync App Setup
Using Your
Smart Humidifier
Using Your Sensor
VeSync App Functions
Care & Maintenance
Troubleshooting
Warranty Information
Customer Support
2
2
3
6
8
10
12
12
13
15
16
21
25
27
Package Contents
1 x Smart Evaporative Humidifier
1 x Wick Filter (Pre-Installed)
1 x Air Filter (Pre-Installed)
1 x Humidity Sensor
1 x AC Power Adapter
1 x User Manual
1 x Quick Start Guide
Specifications
Model Smart Humidifier
LEH-B381S-WNA
Sensor
LSR-B0201EH-WNA
Power Supply 24V 1.5A
Rated Power 19W
Water Tank
Capacity
1 gal / 3.8 L
Max Mist Output 280 mL/h ±15%
Max Runtime Sleep Mode Fan Speed:
Up to 36 hr
Low Fan Speed:
Up to 24 hr
High Fan Speed:
Up to 11 hr
Note: The humidifier may
run for a longer or shorter
time depending on the
environmental temperature
and humidity.
Noise Level* Sleep Fan Mode: < 26dB
Low Fan Mode: < 30dB
High Fan Mode: < 45dB
*Noise test conditions:
4.9 ft / 1.5 m away from
humidifier.
Eective Range 219 ft
2
/ 20 m
2
Dimensions 9.3 x 9.3 x 14.8 in
23.6 x 23.6 x 37.7 cm
Weight 6 lb / 2.73 kg
Noise Level 22–50dB
Power Adapter Input: 100–240V~
50/60Hz, 1.0A Max
Output: 24V 1.5A
Note: To access additional smart
humidifier functions, download the free
VeSync app (see page 12).
