Quick Reference

Learning about the printer

Understanding the printer control panel

Item Description

1 Display Lets you view scanning, copying, faxing, and

printing options as well as status and error

messages

2 Indicator light

• Off—The power is off.

• Blinking green—The printer is warming up,

processing data, or printing.

• Solid green—The printer is on, but idle.

• Blinking red—Operator intervention is

needed.

Item Description

3 Sleep Activates Sleep Mode or Hibernate Mode

The following are the statuses of the indicator

light and the Sleep button:

• Entering or waking from Sleep Mode—The

indicator light is illuminated solid green,

Sleep button is unilluminated.

• Operating in Sleep Mode—The indicator

light is illuminated solid green, Sleep button

is illuminated solid amber.

• Entering or waking from Hibernate Mode—

The indicator light is illuminated solid green,

Sleep button is illuminated blinking amber.

• Operating in Hibernate Mode—The

indicator light is unilluminated, Sleep

button is blinking amber in pulsing pattern.

4 Keypad Lets you enter numbers, letters, or symbols on

the display

5 Submit Lets you submit changes made in the printer

settings

6 Stop/Cancel Stops all printer activity

Note: A list of option is displayed once

Stopped appears on the display.

7 Home Lets you navigate back to the home screen

8 Card reader Limits the use of certain printer functions to

authenticated users

Note: The card reader may not be available on

all printer models.

9 USB port Lets you insert a USB flash drive to send data or

to save scanned images

Understanding the home screen

When the printer is turned on, the display shows a basic screen,

referred to as the home screen. Touch the home screen buttons and

icons to initiate an action such as copying, faxing, or scanning; to open

the menu screen; or to respond to messages.

Note: Your home screen, icons, and buttons may vary depending on

your home screen customization settings, administrative setup, and

active embedded solutions.

Touch To

Copy Access the Copy menus and make copies.

E-mail Access the E-mail menus and send e‑mails.

Fax Access the Fax menus and send fax.

Access the printer menus.

Note: These menus are available only when the

printer is in the Ready state.

FTP Access the File Transfer Protocol (FTP) menus and

scan documents directly to an FTP server.

Status message bar

• Show the current printer status such as Ready

or Busy.

• Show printer conditions such as Toner Low

or Cartridge Low.

• Show intervention messages so the printer can

continue processing.

Status/Supplies

• Display a warning or error message whenever

the printer requires intervention to continue

processing.

• Access the messages screen for more

information on the message, and how to clear

it.

USB or USB

Thumbdrive

View, select, print, scan, or e‑mail photos and

documents from a flash drive.

Note: This button appears only when you return

to the home screen while a memory card or flash

drive is connected to the printer.

Produktspecifikationer

Varumärke:	Lexmark
Kategori:	Skrivare
Modell:	XS796
Inbyggd display:	Ja
Vikt:	66570 g
Bredd:	558 mm
Djup:	508 mm
Höjd:	825 mm
Skärm diagonal:	10.2 "
Processorfrekvens:	1200 MHz
Wi-Fi:	Nej
Maximal upplösning:	1200 x 1200 DPI
Internminne:	1024 MB
Maximalt internminne:	2048 MB
Antal bläckpatroner:	1
Standardgränssnitt:	USB 2.0, Ethernet
Maximal kopieringsupplösning:	600 x 600 DPI
Faxupplösning (svart):	600 x 600 DPI
Fax:	Färgfaxning
Valfri anslutning:	Parallel, Serial (RS-232), Wireless LAN
Allt-i-ett-multitasking:	Ja
Automatisk dokumentmatare (ADF):	Ja
Produktens färg:	Black, White
Inbyggd kortläsare:	Nej
Utskrift:	Färgutskrift
Kopiering:	Färgkopiering
Hållbarhetscertifiering:	ENERGY STAR
Kryptering/säkerhet:	802.1x RADIUS
Nätverksansluten (Ethernet):	Ja
Skanningstyp:	Flatbädds- och ADF-scanner
Bildkomprimeringsformat:	TIF, JPG
Displaytyp:	LCD
Antal USB 2.0 anslutningar:	3
USB-port:	Ja
Namn och uppringnings-ID:	Ja
Positionering på marknaden:	Business
Dokument som stöds:	PDF
Utskriftsteknologi:	laser
Utskriftshastighet (Svart, normalkvalitet, A4/US Brev):	50 ppm
Utskriftshastighet (färg, normal kvalitet, A4/US Letter):	50 ppm
Tid för första utskrift (svart):	8 s
Tid för första utskrift (färg):	8.5 s
Maximal inmatningskapacitet:	2650 ark
Total inmatningskapacitet:	650 ark
Pappersinmatningstyp:	Pappersfack
Total utmatningskapacitet:	500 ark
Maximal utmatningskapacitet:	1000 ark
Högsta ISO A-seriestorlek:	A4
Pappersfackets typ av media:	Banner, Labels, Card stock, Envelopes, Plain paper, Glossy paper, Pre-Printed, Transparencies
ISO A-serie storlek (A0...A9):	A4, A5
Icke-ISO utskriftsmaterial av olika storlek:	Letter (media size), Statement (140 x 216mm), Executive (184 x 267mm), Folio (media size)
Maximal utskriftstorlek:	216 x 297 mm
Optisk skanningsupplösning:	600 x 600 DPI
Skanning:	Färgscanning
Ljudtrycksnivå (utskrivning):	52 dB
Kuvertstorlek:	10, 7 3/4, C5, 9,B5, DL
Skanning till:	USB, E-mail, FTP
Ljudeffektsnivå (vänteläge):	27 dB
Skrivarfäger:	Black, Magenta, Cyan, Yellow
Dubbelsidig skanning:	Ja
Kapacitet för automatisk dokumentmatare:	75 ark
JIS B-serien storlekar (B0...B9):	B5
Fax vidarekoppling:	Ja
