Sida 1/5

7081 878-01

Gebrauchsanweisung für Doppeltür-Kühl-Gefrier-Automaten

Operating instructions for double-door automatic refrigerator-freezers

Consignes d'utilisation pour réfrigérateurs double-porte

Gebruiksaanwijzing voor dubbeldeurs koelkasten

Istruzione d'uso per apparecchi frigo-congelatore a due sportelli

Instrucciones de manejo Frigoríﬁcos de doble puerta con congelador

Instruções de utilização para frigoríﬁcos de duas portas com congelador independente

CUP(esf) 2221/2721/3021

Kullama Kýlavuzu Masaüstü Buzdolaplarý

5010

The appliance at a glance

Defrost drain

* Depending on model and options

Adjustable door racks*

Egg tray*

Ice-cube tray*

Vegetable, salad and fruit bins

Butter stop

Adjustable storage shelves

On/off and temperature control, interior light

Description of appliance and equipment

fig. A

Controls, A1:fig.

1On/off temperature control and

"1" = warm

"7" = cold

We recommend a

medium setting.

2Cool-Plus switch . Switch on at low room temperatures of *

18°C or below.

Interior light

Bulb data: max. 15 W, voltage and current should agree with the

details on the type plate, bulb fitting: E 14.

Replacing the bulb, fig. Switch off the appliance.A1a:

W Pull out the plug or switch off/unscrew the fuse.

W By moving the , you can prevent bottles bottle and can holder

from tipping over when the door is opened and closed. The holder

can be removed for cleaning:

- fig. : The holder slides and releases left or right along the door A2

stops.

W You can remove all for cleaning, fig. : lift rack and door racks A2

pull forwards.

W Shelves* can be adjusted in height for different height items, figs.

A4:

- Lift the shelf, slide forwards and remove.

- Always insert shelves with the raised edge at the back pointing

upwards, otherwise food may freeze onto the rear wall.

W Removing drawers: Pull forward until the drawer stops

and lift out, fig. A3.

W Fig. : If you need space for large bottles and containers, then A5

simply push the front half of glass shelf back. For cleaning, the 1

holder can be used to remove the half glass shelves. 2

Refrigerator, approx. 5°C

Door rack for large bottles

Type/Data plate

Freezer, approx. -18°C

Adjustable-height feet at front, transport castors at back

High drawers,

information system*

Adjustable bottle and can holder

Bottle shelf

Coldest zone of the refrigerator compartment, for sensitive

and perishable foodstuffs

Congratulations on your purchase. In choosing this appliance you have opted for all the benefits of

state-of-the-art refrigeration technology, guaranteeing you top quality, a long life span and excellent

reliability.

The features on your appliance have been designed to ensure maximum convenience - day in, day out.

This appliance has been manufactured with recyclable materials using an environmentally friendly

process, so together you and we are making an active contribution to the preservation of our environ-

ment.

To get to know all the benefits of your new appliance, please read the information contained in these

operating instructions carefully.

We wish you much pleasure with your new appliance.

Contents Page

Operating instructions

The appliance at a glance

..................................... 8

Saving energy ......................................................

Example of food arrangement ..............................

Information system ...............................................

Contents ...............................................................

Safety regulations .................................................

1 Safety instructions and warnings ........................

Disposal notes ....................................................

Setting up ...........................................................

Connecting to the mains .....................................

2 Refrigerator compartment ..................................

Switching the appliance on and off .....................

Setting the temperature ......................................

Cool-Plus switch .................................................

Notes on cooling

................................................. 11

3 Freezer compartment .........................................

Making ice-cubes ...............................................

Notes on freezing and storage

............................ 11

4 Defrosting, cleaning ............................................

5 Troubleshooting .................................................

Customer service and type plate ........................

Instructions for installation and modification

Changing over door hinges ................................ 13

Insertion into row of kitchen units ........................

Example of food arrangement Afig.

1 butter, cheese

2 eggs

3 cans, drinks, bottles

4 preserves, baked goods

5 dairy products

6 coldest area: delicate foods, meat and sausage pro-

ducts, fish, raw milk products, pre-cooked meals

7 fruit, vegetables, salad

8 frozen food, ice-cubes

Safety regulations

W The device is designed exclusively for the cool-

ing foodstuffs. The applicable statutory regula-

tions are to be observed in the event that the device is

to be used for commercial cooling of foodstuffs.

The device is not suitable for the storage and cooling

of drugs, blood plasma, laboratory preparations or

similar medicine-related materials and products as

detailed in the Medical Devices Directive 2007/47/

EC. Improper use of the device can cause the stored

products stored in it to be damaged or the items can

be spoiled. In addition, the device is not suitable for

operation in explosion-prone areas.

W The appliance is set to operate within specific ambi-

ent temperature limits according to its climate rating.

These temperature limits should not be exceeded.

The correct climate rating for your appliance is indi-

cated on the type plate. This is explained as follows:

Climate rating Set for ambient temperatures of

SN +10°C to +32°C

N +16°C to +32°C

ST +16°C to +38°C

T +16°C to +43°C

- The refrigerant circuit has been tested for leaks.

- The appliance complies with current safety regulations

and EC directives 2006/95/EC and 2004/108/EC.

Information system

Use frozen food within the recommended period.

The numbers between the symbols indicate the storage

period in months for different kinds of frozen foods.

Storage times given are guide times for food frozen at

home. Whether or not the lower or upper value is applicable

depends on the food quality and how it was pro-cessed prior

to freezing. The lower values always apply to food with a

high fat content.

The symbols have the following signification:

pre-cooked meals

ice-cream

fish

pork

vegetables

fruit

game

sausages

mushrooms

bread

poultry

beef/veal

Keep these operating instructions in a safe place and pass

them on to the next owner, where applicable.

The operating instructions apply to several models. Differ-

ences may therefore occur.

Note

- Place food inside the appliance as shown in the diagram. This

allows the appliance to save energy during operation.

- Shelves, drawers and baskets are arranged for optimum

energy efficiency on delivery.

Saving energy

- Always ensure good ventilation. Do not cover ventilation

openings or grille.

- Do not place appliance in areas of direct sunlight or next to a

stove, heater or similar object.

- The energy consumption depends on the installation condi-

tions, e.g. the ambient temperature.

- Keep the time the appliance is open to a minimum.

The lower the temperature setting, the higher the power consumption.

- Store food logically. (see Appliance at a glance).

- Ensure that all food is well packed and covered for storage.

This will prevent frost from forming.

Remove food as needed in order that it does not warm too much.

- First cool warm food to room temperature before storing it.

- Defrost frozen food in the refrigerator.

- If there is a thick layer of frost in the ap-

pliance: defrost the appliance.

Accumulated dust increases the energy

consumption:

- Once a year, dust the refrigerating unit

together with the metal grille of the heat

exchanger at the back of the appliance.

Produktspecifikationer

Varumärke:	Liebherr
Kategori:	kylskåp
Modell:	CUP 3021
Bredd:	550 mm
Djup:	628 mm
Höjd:	1800 mm
Årlig energiförbrukning:	262 kWh
Energieffektivitetsklass (gammal):	A+
Fryskapacitet:	7 kg/24h
Frysläge:	Bottom-placerade
antal stjärnor:	4*
Inbyggd frys:	Ja
Strömförsörjning:	220/240 V
Produktens färg:	Vit
Lagringstid vid strömavbrott:	24 h
Apparatens placering:	Fristående
Gångjärnssida:	Höger
Hängbar dörr:	Ja
Total kapacitet netto:	284 l
Ljudnivå Lc IEC:	40 dB
Klimatkategori:	SN-ST
Innerbelysning, kyl:	Ja
Frostfri (kyl):	Nej
Ansluten effekt:	- W
Fryskapacitet netto.:	85 l
Fryskapacitet brutto:	87 l
Total kapacitet, brutto:	290 l
Kylkapacitet brutto:	203 l
Kylkapacitet netto:	199 l
Vattenberedare:	Nej
Frostfri (frys):	Nej
