Operating instructions

Combined fridge-freezer

120116

7082858 - 01

CU(sl)(ef)(ag)(fr)(wb) 2311/2811/3311 ... 1

Contents

1 Appliance at a glance............................................ 2

1.1 Description of appliance and equipment.................. 2

1.2 Appliance range of use............................................. 2

1.3 Conformity................................................................ 3

1.4 Installation dimensions............................................. 3

1.5 Saving energy.......................................................... 3

2 General safety information................................... 3

3 Controls and displays........................................... 4

3.1 Operating controls.................................................... 4

4 Putting into operation............................................ 4

4.1 Transporting the appliance....................................... 4

4.2 Installing the appliance............................................. 5

4.3 Changing over the door hinges................................ 5

4.4 Insertion into a row of kitchen units........................... 7

4.5 Disposing of packaging............................................ 7

4.6 Connecting the appliance......................................... 7

4.7 Switching on the appliance....................................... 7

5 Control.................................................................... 8

5.1 Refrigerator compartment........................................ 8

5.2 Freezer compartment............................................... 9

6 Maintenance........................................................... 10

6.1 Manual defrosting..................................................... 10

6.2 Cleaning the appliance............................................. 10

6.3 Changing the interior light......................................... 10

6.4 Customer service..................................................... 11

7 Malfunctions........................................................... 11

8 Decommissioning.................................................. 12

8.1 Switching off the appliance....................................... 12

8.2 Taking the appliance out of service.......................... 12

9 Disposing of the appliance................................... 12

The manufacturer works constantly on the further development

of all the types and models. Therefore please understand that

we have to reserve the right to make design, equipment and

technical modifications.

To get to know all the benefits of your new appliance, please

read the information contained in these instructions carefully.

The instructions apply to several models. Differences may

occur. Text relating only to specific appliances is marked with

an asterisk (*).

Instructions for action are marked with a , the results of

action are marked with a .

1 Appliance at a glance

1.1 Description of appliance and equip-

ment

Note

Place food inside the appliance as shown in the diagram.

This allows the appliance to save energy during operation.

Shelves, drawers and baskets are arranged for optimum

energy efficiency on delivery.

Fig. 1

(1) (8)Adjustable shelves Coldest area in the refrig-

erator compartment, for

sensitive and perishable

foodstuffs

(2) (9)Egg tray Adjustable bottle and jar

shelf

(3) (10)Butter shelf Vegetable, salad and fruit

bins

(4) (11)Adjustable door shelf Type plate

(5) On/Off and temperature

controller and interior

lighting

(12) Deep freezer drawers

(6) (13)Defrost water drain Adjustable feet at the front

(7) (14)Bottle rack Ice cube tray

1.2 Appliance range of use

Intended use

The appliance is only suitable for refrigerating

food in a domestic or domestic-like environ-

ment. This includes, for example, using

in staff kitchens, bed and breakfast establish-

ments,

by guests in country houses, hotels, motels

and other accommodation,

for catering and similar services in the whole-

sale trade.

All other types of use are not permitted.

Foreseeable misuse

The following applications are expressly

forbidden:

Storing and refrigerating medicines, blood

plasma, laboratory preparations or similar

substances and products based on the

Medical Device Directive 2007/47/EC

Use in areas at risk of explosions

Use on moving substrates, such as ships, rail

travel or aeroplanes

Storing live animals

Appliance at a glance

2 * Depending on model and options

Misusing the appliance may lead to damage to

the goods stored or they may spoil.

Climate classifications

Depending on the climate classification the

appliance is designed to operate in restricted

ambient temperatures. The climate classifica-

tion applying to your appliance is printed on the

rating plate.

Note

Keep to the specified ambient temperatures

in order to guarantee that the appliance works

properly.

Climate clas-

sification

for ambient temperatures of

SN 10 °C to 32 °C

N 16 °C to 32 °C

ST 16 °C to 38 °C

T 16 °C to 43 °C

1.3 Conformity

The refrigerant circuit is tested for leakage. The appliance

complies with the relevant safety regulations and EC Directives

2006/95/EC, 2004/108/EC, 2009/125/EC and 2010/30/EU.

Note for test institutions:

Tests are to be carried out according to the applicable

standards and guidelines.

Preparation and testing of the appliances must be carried

out taking the and themanufacturer's loading plans

notes in the operating manual into account.

1.4 Installation dimensions

Fig. 2

CU(sl) 2311 1372

CU(sl)(ef) 2811 1612

CU(ef)(ag)(fr)(wb) 3311 1812

This dimension increases by 35 mm (see 4.2) with devices

that use wall spacer brackets.

1.5 Saving energy

Pay attention to good ventilation. Do not cover ventilation

holes or grids.

Do not install the appliance in direct sunlight, next to an

oven, radiator or similar.

Energy consumption depends on the installation conditions,

e.g. the ambient temperature (see 1.2) .

Open the appliance for as short a time as possible.

The lower the temperature is set the higher the energy

consumption.

Sort food before arranging (see Appliance at a glance).

Store all food well packaged and covered. A build up of frost

is avoided.

Only take food out for as long as necessary so that it doesn’t

warm up too much.

Inserting hot food: let it cool to room temperature first.

Thaw frozen food in the refrigerator.

If there is a thick layer of frost in the appliance: defrost the

appliance.

Dust deposits increase energy consump-

tion:

For refrigerators with heat exchangers

dust the metal grid on the back of the

appliance once a year.

2 General safety information

Danger for the user:

This appliance can be used by children of 8

years old and over, and also by persons with

restricted physical, sensory or mental

capacity or lack of experience and knowl-

edge, if they are supervised or have been

instructed on safe use of the appliance and

understand the resulting risks. Children must

not be allowed to play with the appliance.

Cleaning and user maintenance must not be

carried out by children without supervision.

When disconnecting the appliance from the

supply, always take hold of the plug. Do not

pull the cable.

In the event of a fault pull out the mains plug

or deactivate the fuse.

Do not damage the mains power cable. Do

not operate the appliance with a defective

mains power cable.

Have any repairs to or intervention in the

appliance, and any change of the mains

power cable, carried out by the customer

service only or by other specialised personnel

trained for the purpose.

Only assemble, connect and dispose of the

appliance according to the instructions.

General safety information

* Depending on model and options 3

Produktspecifikationer

Varumärke:	Liebherr
Kategori:	kylskåp
Modell:	CUWB 3311
Bredd:	550 mm
Djup:	629 mm
Höjd:	1812 mm
Årlig energiförbrukning:	210 kWh
Energieffektivitetsklass (gammal):	A++
Fryskapacitet:	4 kg/24h
Frysläge:	Bottom-placerade
antal stjärnor:	4*
Flaskställ:	Ja
Antal kompressorer:	1
Automatisk avfrostning (frys):	Nej
Justerbara fötter:	Ja
Produktens färg:	Blå
Kontrolltyp:	Knappar
Lagringstid vid strömavbrott:	- h
Lamptyp:	LED
Material, hölje:	Stål
Antal hyllor i frysen:	4
Apparatens placering:	Fristående
Isbricka:	Ja
Gångjärnssida:	Höger
Hängbar dörr:	Ja
Hyllor material:	Härdat glas
Total kapacitet netto:	294 l
Ljudnivå Lc IEC:	39 dB
Klimatkategori:	SN-ST
Innerbelysning, kyl:	Ja
Frostfri (kyl):	Nej
Automatisk avfrostning (kyl):	Ja
Multi-luftflödessystem (kyl):	Nej
Antal vegetabiliska lådor:	2
Äggfack:	Ja
Ansluten effekt:	- W
Frys - Antal hyllor:	3
Fryskapacitet netto.:	84 l
Fryskapacitet brutto:	86 l
Total kapacitet, brutto:	304 l
Kylkapacitet brutto:	218 l
Kylkapacitet netto:	210 l
Frostfri (frys):	Nej
Innerbelysning, frys:	Ja
