Sida 1/12
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - SECOND EDITION (MARCH 2016)
USB Digital to Analog Converter ue
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale Italiano
LINDY No. 20376
www.lindy.com
User Manual English
Introduction
Thank you for purchasing the LINDY USB DAC (Digital- -Analog Audio Converter) with USB to ue
connectivity & head phone amplifier. The DAC converts digital PCM (Pulse Code Modulation) audio to
stereo audio signals and acts a USB digital audio interface allowing you to connect your analogue audio
system to a wide range of digital audio sources.
Features
Provides audiophile sound quality up to 24bit/192kHz
Accepts 2 channel digital audio and works with any PCM stream with Dolby Digital or DTS disabled
Optical, Coaxial and USB Digital Audio interfaces
Input selector switch and headphone volume control
USB 2.0 interface compatible with Windows XP/Vista/7/8/10 and Mac OS X
Can be powered via the USB bus or an additional USB power supply (not included)
Package Contents
LINDY USB Digital to Analog Audio Converter ue
USB Type A/B Cable, 1m
This manual
Specification
Input ports: 1 x USB Type B, 1 x TOSLink (Optical Fibre), 1 x Coaxial
Output ports: 2 x Phono Left & Right, 3.5mm Headphone Socket
Integrated Digital to Analog Converter (DAC)
USB Audio Interface
Supports 2 channel LPCM
-bit incoming bitstream on left and right channels 24
Sampling Frequency (or Supported Sample Rates)
o Toslink/Coaxial SPDIF 44.1 192k –Hz
o USB 44.1 k –96 Hz
Headphone Sound Output Power:
o 60mW @ RL=16Ohm THD <0.1%
o 30mW @ RL=32Ohm THD <0.1%
Volume Control dial
User Manual English
Overview
1. Digital Input Switch
Select one of the three digital inputs, Optical,
Coaxial USB by setting the slide switch as or
follows:
Position Input Mode LED Colour
1 Optical Red
2 Coaxial Orange
3 USB Green
2. Optical Input
Connect a digital audio source device such as a
Bluray player, DVD player or set top box using a
Toslink cable to receive audio at up to 24bit/192kHz
3. Coaxial Input
Connect a digital audio source device such as a Bluray player, DVD player or set top box using a
Coaxial cable to receive audio at up to 24bit/192kHz
4. USB Port
Connect a desktop or laptop computer and use the DAC as an external sound card, playing high
definition audio directly from your computer via USB. Requires no additional drivers or software.
The USB port can also be used to connect a DC 5V power supply (not included)
5. Line Out
Connect an amplifier or active speakers using
standard stereo phono cables to output sound
6. Headphone Socket
Connect your headphones
7. Volume Control Dial
Adjust the volume output of the DAC
Warning: Always start with the volume dial at the minimal
setting before connecting headphones. This will
help ensure you don t get unexpected high volume ’
levels that could damage your hearing
Installation
1. Power down the equipment that the DAC will be attached to
2. Connect the relevant input/output cables as described above
3. Set the Input switch to the desired selection
4. If the DAC is not connected to a computer connect it to a USB power supply (not included) that is
capable of providing 5V 500 1000mA –
5. Power up the source device and begin audio playback
Please Note: The USB DAC is not compatible with Dolby Digital or DTS formats, which are both forms
of compressed audio. If you play back CDs, DVDs or BDs encoded in Dolby Digital or DTS, you will only
hear some unwanted noise that may damage your speakers. To work around this you need to access
the menu setting of the source device and adjust Dolby Digital or DTS to PCM. This USB DAC works
with any PCM stream from CD players, DVD players and set-top boxes.
5
6
7
1
2
3
4
