Sida 1/16

2 Port DVI-D / VGA / DP 1.2 / HDMI,

USB 2.0 & Audio Cable KVM Switch

User Manual English

Benutzerhandbuch Deutsch

Manuel Utilisateur Français

Manuale Italiano

No.

4234 10.20 2 Port HDMI , USB 2.0 & Audio KVM Switch

42341 2 Port DVI-D Single Link, USB 2.0 & Audio KVM Switch

42342 2 Port VGA, USB 2.0 & Audio KVM Switch

42344 2 Port DisplayPort 1.2, USB 2.0 & Audio KVM Switch

42345 2 Port HDMI 18G, USB 2.0 & Audio KVM Switch

lindy.com

User Manual English

Introduction

Thank you for purchasing the . This product has been designed to provide trouble Lindy Cable KVM Switch

free, reliable operation. It benefits from both a LINDY year warranty and free lifetime technical support. 2-

To ensure correct use, please read this manual carefully and retain it for future reference.

Package Contents

 KVM Switch with cables

 This Manual

Features

 USB 2.0

 Simple switching via push button, software and keyboard hotkeys

 3.5mm Audio output allows users to connect headphones or speakers to add immersive 2-channel

audio and a microphone

 USB peripherals can be integrated with a USB hub when connected to the USB female port

 LED Indicators for identifying the active connection

 Integrated c for a direct ables connection devicesto the

42340: Console Interfaces: HDMI (Female), USB 2.0 Type A (Female), 2 x 3.5mm (Female)

PC/Server Interfaces: HDMI (Male), Type A (Male) 2 x 3.5mm (Male) 0.9m integrated cablesUSB 2.0 ,

Supports resolutions up to 3840x2160@30Hz 4:4:4 8bit compliant, HDCP 1.4

42341: Console Interfaces: DVI-I (Female), USB 2.0 Type A (Female), 2 x 3.5mm (Female)

PC/Server Interfaces: DVI Type A (Male) 2 x 3.5mm (Male) 0.9m integrated cables- D (Male), USB 2.0 ,

Supports DVI-D Single Link up to 1920x1200, HDCP compliant resolutions – not for connection to

HDMI ports of graphic cards or PC/notebook, HDMI and Deep Colour are not supported

42342: Console Interfaces: VGA (Female), USB 2.0 Type A (Female), 2 x 3.5mm (Female)

PC/Server Interfaces: VGA (Male Type A (Male) 1.2m integrated cables), USB 2.0 , 2 x 3.5mm (Male)

Supports VGA resolutions 536@60Hz, HDCP not supported up to 2048x1

42344: Console Interfaces: DisplayPort 1.2 (Female), USB 2.0 Type A (Female) 2 x 3.5mm (Female),

PC/Server Interfaces: DisplayPort 1.2 Type A (Male) (Male), USB 2.0 , 2 x 3.5mm (Male) 1.2m

integrated cables

Supports resolutions up to 3840x2160 60Hz 4:4:4 8bit, HDCP 1.4 compliant

42345: Console Interfaces: HDMI (Female), USB 2.0 Type A (Female), 2 x 3.5mm (Female)

PC/Server Interfaces: HDMI (Male), Type A (Male) 2 x 3.5mm (Male) 1.2m integrated cablesUSB 2.0 ,

Supports resolutions up to 3840x2160 60Hz 4:4:4 8bit, HDCP 1.4 compliant@

Specification

 Black, pl astic housing

 Power requirements: Powered via USB

Produktspecifikationer

Varumärke:	Lindy
Kategori:	Inte kategoriserad
Modell:	42345
Inbyggd display:	Nej
Vikt:	436 g
Bredd:	97 mm
Djup:	82.18 mm
Höjd:	25 mm
Förpackningens bredd:	160 mm
LED-indikatorer:	Ja
Maximal upplösning:	4096 x 2160 pixlar
Antal HDMI-portar:	1
Hörlursutgångar:	1
Certifiering:	CE, FCC, REACH
HDCP:	Ja
HDMI-version:	2.0
Rackmontering:	Ja
Antal mikrofoningångar:	1
Antal datorer:	2
Konsolportar:	3.5mm headphone, 3.5mm mic, HDMI, USB A
Videobandbredd:	60 hz
Kabellängd:	1.2 m
Produktens färg:	Svart
bruksanvisning:	Ja
HD-typ:	4K Ultra HD
Förpackningstyp:	Låda
Låddjup:	60 mm
Vikt inkl. förpackning:	517 g
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	0 - 90 %
Hållbarhetscertifiering:	RoHS
Video porttyp:	HDMI
Material, hölje:	Plast
Strömkälla:	DC
Harmonized System (HS)-kod:	85176200
Tangentbord anslutningstyp:	USB
Mus porttyp:	USB
Antal USB-konsolportar:	2
