Sida 1/8
© LINDY Group - FIRST EDITION (August 2019)
140m 4 Port USB 2.0 Cat.6 Extender
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale Italiano
No. 42710
lindy.com
Tested to comply with
FCC Standards
For Home and Oce Use!
User Manual English
Introduction
Thank you for purchasing the Lindy 140m 4 Port USB 2.0 Cat.6 Extender. This product has been designed
to provide trouble free, reliable operation. It benefits from both a LINDY 2 year warranty and free lifetime
technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
This Lindy USB 2.0 Cat.6 Extender extends the distance between four USB peripheral devices and the
computer up to distances of 140m (459.31ft) using a single Cat.6 UTP or higher network cable and up to
120m (393.7ft) with a Cat.5e UTP/STP cable. Optionally, these distances can be doubled by use of a
signal repeater (No. 42709).
Package Contents
• Transmitter Unit (Tx)
• Receiver Unit (Rx)
• USB 2.0 A/B male cable (approximately 50cm)
• Multi-Country Power Supply, 5 2 A with DC connector 5.5/2.5 and adapters (EU, UK, US, DC V .6 mm
AUS)
• 2 sets with 4 screws & 4 dowels for transmitter and receiver
• This Manual
Features
• Supports USB 2.0 high-speed and USB 1.1 (full-speed, low-speed) devices
• Integrated four port USB hub
• Supports distances up to 14 (459.31ft) using low cost Cat.6 (or better) UTP cables 120m 0m and
(393.7ft) with low cost Cat.5e UTP/STP cables
• The max. distance can be doubled up to 240m (787.39ft) or 280m (918.62ft) by using the signal
repeater No. 42709
• Green LED for power and blue LED for visual confirmation of a successful link
• Supports all major Operating Systems with USB support
• Transmitter and Receiver units both feature integrated mounting brackets
Specication
• Transmitter: Input Port 1x USB 2.0 Type B, Output Port 1x RJ45
• Receiver: Input Port 1x RJ45, Output Port 4x USB 2.0 Type A, DC Socket for PSU 5.5/2.5mm
• Dimensions: Tx: 120x67x27mm (4.72x2.64x1.06in) Rx: 130x67x27mm (5.12x2.64x1.06in) ,
• Weight: Tx: 0.19kg (0.42lb), Rx: 0.21kg (0.46lb)
• Operating Temperature: 0° - 55°C (32°F - 131°F)
• Storage Temperature: -20°C - 85°C (-4°F - 185°F)
• Humidity: - 95% RH (non-condensing) 0
Installation
1. Connect the transmitter to a USB por o th host computer by using the included USB cable.t n e
2. Place the receiver unit near the USB device(s) in the desired remote location.
3. Connect the power adapter to the receiver unit.
4. Connect the transmitter to the receiver unit by using a Cat.5e/6 (or better) cable (not included).
5. The Extender is now correctly installed and the USB devices can be connected.
