USB 3.1 Type C Multi-Port Converter

User Manual English

Benutzerhandbuch Deutsch

Manuel Utilisateur Français

Manuale Italiano

No. 78 432

lindy.com

Tested to comply with

FCC Standards

For Home and Oce Use!

User Manual English

Introduction

Thank you for purchasing the USB 3.1 Type C Multi-Port Converter This product has been designed to

provide trouble free, reliable operation. It benets from both a LINDY 2 year warranty and free lifetime

technical support. To ensure correct use, please read this manual carefully and retain it for future

reference.

This USB 3.1 Type C Multi-Port Converter allows you to maximise the functionality of a single USB 3.1

Type C port by connecting an HDMI display, a VGA monitor, up to three USB 3.1/3.0 SuperSpeed

peripherals as well as a USB Type C power supply to your Macbook or notebook. Through the RJ45 port

you can access a Gigabit Ethernet Network and it is also possible to access SD or microSD cards. Please

note that a USB 3.1 Type-C port with support for DisplayPort Alternate Mode is required for video

functionality.

Package Contents

▪ USB 3.1 Type C Multi-Port Converter

▪ This manual

Features

▪ Compatible with all USB Type C equipped computers with DisplayPort Alternate Mode

▪ Input: USB 3.1 Type C connector – male, 1x USB Type C female (only for charging, no data transfer)

▪ Output: HDMI A female, VGA female, 3x USB Type 3.1 Gen 1 / 3.0 Type A female, RJ45 female, SD

and microSD card slot

▪ USB 3.1 Gen 1 / 3.0 standard (5 Gbps)

▪ Max. resolution: 3840 x 2160 30Hz (HDMI), 1920x1080@60Hz (VGA)

▪ Works as a splitter if both VGA and HDMI are connected at the same time, max. resolution

1920x1080@60Hz with the same video content

▪ 10/100/1000Mbps Gigabit Ethernet

▪ USB Type C Power Delivery input port for charging (no data transfer) with max. 0W (20V / 510 A)

Installation & Operation

The USB 3.1 standard allows USB ports to optionally feature DisplayPort Alternate Mode; this uses the

USB C connector as a video output without the need for additional drivers or software. Please check that

your computer supports this feature.

To begin using this Multi-Port Converter simply connect the USB 3.1 Type C male connector to the USB

3.1 Type C port of your computer. Any required drivers will be automatically downloaded from the internet.

Connect the HDMI socket and/or VGA socket of the converter to the HDMI/VGA port of your monitor or

projector using appropriate male to male cables (not included). Use a standard RJ45 Ethernet cable (not

included) to connect to your network. Additional USB devices can be connected to the USB Type A ports

of the Mini Docking Station, USB 3.1 Gen1 5Gbps data transfer rates are supported whilst legacy USB

2.0/1.1 devices may also be connected. The SD and microSD card slots allow access to SD and micro SD

cards.

By connecting a compatible USB Type C power supply (not included) it is also possible to charge your

Macbook or Notebook using the Type C Power Delivery port, just connect the power supply to the Power

Delivery port when required.

Produktspecifikationer

Varumärke:	Lindy
Kategori:	Inte kategoriserad
Modell:	43278
Vikt:	90 g
Bredd:	180 mm
Djup:	17 mm
Höjd:	49 mm
Förpackningens bredd:	174 mm
Videolägen som stöds:	1080p, 2160p
Antal HDMI-portar:	1
Certifiering:	CE, UKCA, FCC, REACH, RoHS, CP65
HDCP:	Ja
Grafikupplösningar som stöds:	1920 x 1080 (HD 1080), 3840 x 2160
Värdgränssnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
HDCP-version:	2.2
Hub-gränssnitt:	HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, VGA
Kortläsare:	2
Typ av minneskort:	MicroSD (TransFlash), SD
Produktens färg:	Grå
bruksanvisning:	Ja
Förpackningstyp:	Polypåse
Låddjup:	194 mm
Vikt inkl. förpackning:	100 g
Antal per förpackning:	1 styck
Inbyggd kortläsare:	Ja
USB-strömförsörjning upp till:	100 W
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 45 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	20 - 80 %
Fuktighet (förvaring):	20 - 80 %
Material, hölje:	Gjuten aluminium
Minsta drifttemperatur:	0 ° C
Maximal arbetstemperatur:	45 ° C
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	3
Harmonized System (HS)-kod:	84719000
Kretsar:	RTL8153B, EP9632G, GL3510
Faktisk dataöverföringshastighet:	5000 Mbit/s
Antal anslutningar:	7
Nätaggregatstyp:	USB
Kvalitet på VGA (D-Sub) porten:	1
Omgivningstemperatur vid drift:	32 - 113 ° F
USB-strömleverans:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1)typ C-portar:	1
Revision av USB-strömförsörjning:	3.0
Högsta upplösning (HDMI):	3840 x 2160 pixlar
Alternativt läge för USB Typ-C DisplayPort:	Ja
