EC-1-DV & EC-1K-DV Series

OWNER'S MANUAL

English

EN

This pump is designed to automatically remove condensate water

that drips from wall mount ductless air conditioners up to 34,000

BTU/hr. The EC-1-DV pump is only suitable for intermittent use in

applications with a maximum 50% pump duty cycle and maxi-

mum 3-minute pump ON cycle. To maintain a maximum 50%

duty cycle, the pump must have at least twice the flow rate of the

condensate produced at the head required by the application.

The pump is controlled by a float switch mechanism, which auto-

matically starts and stops the pump. These models also include a

high water level switch, which opens a thermostat circuit or breaks power to the machine when the pump

reservoir is full, stopping production of condensate. Alternatively, this switch can be reconfigured to close a

circuit and operate a relay to sound an alarm, power a warning light, or signal a building management sys-

tem (alarm, light, and BMS are purchased separately).

This product is covered by a Limited Warranty for a period of 2 years from the date of original purchase by

the consumer. For complete warranty information, refer to www.LittleGiant.com

.

Specifications

Model

Item

Number

VoltsHzAmpsWatts

EC-1-DV553507

110-24050/600.1818

EC-1K-DV553517

Model

Item

Number

Gallons (Liters) per Hour at Height

Shut Off

ft (m)

0 ft

(0.0 m)

1 ft

(0.3 m)

5 ft

(1.5 m)

10 ft

(3.0 m)

20 ft

(6.1 m)

EC-1-DV553507

2.7 (10.2)2.5 (9.5)1.8 (6.8)1.5 (5.7)1.2 (4.5)33 (10)

EC-1K-DV553517
