Sida 1/2
FOR SUPPORT AND INFORMATION,
VISIT WWW.LOREXTECHNOLOGY.COM
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
Contents
• IP Bullet Camera*
• Mounting Kit*
• 100ft Cat5e Ethernet Cable*
Copyright © 2013 Lorex Technologies Inc.
As our products are subject to continuous improvement, Lorex reserves the right to modify product
design, specifications and prices, without notice and without incurring any obligation. E&OE
Camera Specifications
Image Sensor 1/3” Color Image Sensor
Video Format NTSC
Effective Pixels H: 1920 V: 1080
Resolution 1080P @ 30FPS (Frames Per Second)
Scan System Progressive
Sync System Internal
Iris Auto Iris
AES Shutter Speed 1/25 ~ 1/100,000 Sec.
Min. Illumination 0.1 Lux without IR LED
0 Lux with IR LED
Lens / Lens Type 4mm F1.2 / Fixed
Digital Noise Reduction 3D-DNR
Wide Dynamic Range Digital WDR
FOV (Diagonal) 75°
Termination RJ45 10 M / 100M Ethernet
IR LED Qty. / Type 30 pieces / 850nm
Night Vision Range* 100ft (30m) / 150ft (45m)
Power Requirement PoE (Power over Ethernet) Class 2 /
12V DC
Power Consumption 350mA
Operating Temp. Range 14° ~ 140°F / –10° ~ 60°C
Operating Humidity Range < 95% RH
Indoor/Outdoor** Both (IP66)
Weight (including stand) 0.9lbs / 0.4kg
* Stated IR illumination range is based on ideal conditions in total darkness and in typical outdoor
night time ambient lighting. Actual range and image clarity depends on installation location, viewing
area and light reflection / absorption level of object.
** Not intended for submersion in water. Installation in a sheltered location recommended.
ATTENTION - It is recommended to connect the camera to the NVR or
an external PoE switch. If using a DC power adapter with the camera, a
REGULATED UL / CSA APPROVED power supply is REQUIRED for use with this
camera. Use of a non-regulated, non-conforming power supply can damage
this product and voids the warranty.
Features
• H.264 video compression technology
• Full HD1080P resolution
• Plug-and-play Power over Ethernet (PoE) connection to NVR
• Camera is automatically detected when connected to the same local
network of the NVR using Cat5E power and video over Ethernet for
simple and flexible installation
• 3D DNR - Frame-to-frame Digital Noise Reduction combined with Spatial
Noise Reduction, delivering a cleaner, more accurate image, with better
clarity, sharpness, greater disc space for storage, and improved motion
detection.
• Digital-Wide Dynamic Range backlight compensation provides clear
detailed images where very bright and very dark areas are in the same
field of view and frame of the camera.
• Outstanding Night Vision up to 150ft away in typical night time ambient
lighting and up to 100ft away total darkness*
• Automatic Infrared Filter ensures true & accurate color in all lighting
conditions
• Wide angle 4mm lens for superior detail (75° diagonal FOV)
• Weatherproof (IP66) rated aluminum housing for indoor/outdoor
installations**
• Vandal-resistant design: Cable pass-through wall-mount bracket protects
connection cables
• Close-up recognition at night with auto light compensation prevents wash-
out effect
• Anti-glare feature ensures clear images under strong lighting conditions
• Set It and Forget It -Auto-Detect pre-configured cameras***
Disclaimers:
* Stated IR illumination range is based on ideal conditions in total darkness and in typical outdoor
night time ambient lighting. Actual range and image clarity depends on installation location,
viewing area and light reflection / absorption level of object.
** Not intended for submersion in water. Installation in a sheltered location recommended.
*** 1 minute discovery time when connecting a new camera to NVR.
Warning/Caution
• Use the camera only with compatible Lorex NVRs
• Read this guide carefully and keep it for future reference
• Follow all instructions for safe use of the product and handle with care
• Use the camera within given temperature, humidity and voltage levels
noted in Camera Specifications
• Do not disassemble the camera
• Do not point the camera directly towards the sun or a source of intense
light
• Periodic cleaning may be required. Use a damp cloth only. Do not use
harsh cleaners or aerosol cleaners
• The supplied extension cable is rated for surface mounting only
• Cables for in-wall / floor-to-floor installations are sold separately
Installation Tips
• Point the camera where there is the least amount of obstructions (i.e. tree
branches)
• Install the camera in a location that is difficult for vandals to reach
• Secure cabling so that it is not exposed or easily cut
• Camera rated for outdoor use. Installation in a sheltered location
recommended
WEATHERPROOF HIGH DEFINITION
NIGHT VISION IP SECURITY CAMERA
Quick Start Guide
English Version 1.0
LNB2153 SERIES
154mm / 6.1”
65mm / 2.6”
Dimensions
* Per camera.
65mm / 2.6”
