Sida 1/6
Function keys
Zooms out the Radar, Sonar and Chart pages.
ZOUT
Zooms in the Radar, Sonar and Chart pages.
ZIN
Press to return to a previous screen, clear data and
close menus. Pressing on the Chart page will ExIT
quickly switch between displaying the boat symbol
and the last cursor position.
ExIT
Press to save data, change values and accept menu
commands; also acts as a short cut key for important
functions such as saving a waypoint at the cursor
position on the Chart page.
ENTER
Accesses the features available on each page.
MENU
Press to select the page (screen) to display or to access utilities such as
the waypoints list and celestial table. Press and hold to switch control
between the panels and combo (split screen) pages.
PAGES
Press to turn the unit on, adjust the backlight or place the unit in low
power (standby) mode. Press and hold to turn the unit off.
LIGHT
POWER
Activates cursor. Press up, down, left or right to
move the cursor.
Arrow
Keypad
Press to save a waypoint at your current GPS position. Press and hold
to search for waypoints and other points of interest (POI's) or quickly
access waypoints, routes and trails..
WPT
FIND
Creating a Man Overboard (MOB) position
Press the and keys at the same time to create a MOB waypoint with a ZOUT ZIN
line to your boat position.
Quick Start Guide
HDS-8/8m & HDS-10/10m
To view a page:
1. From any screen press PAGES to access the Pages screen.
Select the the desired page display. 2.
To adjust Panel sizes on a Combo page:
1. From the Pages screen select the desired combo page and press
the key. Selecting Sonar + Chart will display a Sonar and MENU
Chart combo page.
Select 2. . and press . Adjust panel sizes ENTER
Use the keypad to adjust the panel size.3.
To add a Data or Gauge overlay to a page:
1. To add/edit data overlay, select the desired page from the pages
screen and press . MENU
Select 2. and pressEdit data overlay .ENTER
When the page appears press 3. to select data or to ENTER MENU
access the edit overlay menu.
To access softkey features, press the button below the softkey. When you have
nished making adjustments press the softkey button again to close the menu.
Pages screen
Softkeys
Chart page softkeys
NOTE: Hold down the PAGES key to switch active panels
when viewing a combo page.
Sonar (Sonar units only)
Cursor
Press the keypad to the left to scroll the Sonar page back to view previous
sonar returns. When the cursor is onscreen the sonar does not show real
time sonar returns. Press to return to normal operation. ExIT
Cursor depth Fish arches Brush pile
Information at
cursor's position Range scale
Amplitude
scope
History bar
Transducer Type
Selecting the proper transducer type from the sonar installation menu helps optimize
HDS performance by enabling settings (temperature and frequency) and menu
options specic to your transducer.
To select a Transducer Type:
Press 1. twice.MENU
Select 2. and press . Sonar ENTER
Select 3. and press . Installation ENTER
Select the desired transducer type 4.
and press . ENTER
Highlight 5. and press .Save ENTER
Transducer type menu
