MoonLite
2
INTRODUCTION
Thank you for buying a LumenRadio MoonLite
2
product. This guide is intended to give you a quick
start to experience all the benets of being wireless with LumenRadio’s CRMX system. For a more
complete user guide, scan the QR code or visit our website.
The MoonLite
2
you just purchased is designed to give you the highest level of reliability on the market
and is fully compatible with other CRMX products. Through this you can expand your wireless system
with units from our other CRMX product lines as well as products from our partners. For the latest
updates, please visit our website www.lumenradio.com.
We hope that you will enjoy the benets and freedom that your new MoonLite
2
will give you.
YOUR MOONLITE
2
MoonLite
2
MANUAL MoonLite
2
Copyright © LumenRadio AB 2025, All Rights Reserved www.lumenradio.com
LUMENRADIOMANUAL MoonLite
2
Copyright © LumenRadio AB 2025, All Rights Reserved www.lumenradio.com
LUMENRADIO
CHARGING
Your MoonLite
2
has a built-in battery to allow for true wireless operation. The battery can be recharged
in two ways:
1. Via the USB-C connector.
2. In a dedicated charging case (sold separately).
MoonLite
2
can be charged from any standard USB port or charger that can supply 5V and minimum 500mA.
If the unit is charging from the USB-C port, the unit is still operational, which allows it to run directly
from external power, for instance from a USB port on a xture.
When MoonLite
2
is charging in its charging case, the unit is not operational. This is to reduce the risk
of unwanted linking or unwanted RF emissions while charging.
SPECIFICATIONS
Power supply DC: 5 VDC +/- 10%
Max. current input (while charging): 500mA
Self-healing fuse: Yes
IP rating: IP 20
Dimensions (W x H x D): TBD [mm]
Weight: TBD g
Antenna: Integral antenna
Operating temp. range: -20 to +55 °C
Storage temp. range: -30 to +80 °C
Humidity: 0 – 90% non-condensing
Frequency range: 2402 – 2480 MHz (ISM band)
Max. RF output power: 280 mW (in North America only)
Supported protocols: DMX-512A (ANSI E1.11), RDM (ANSI E1.20)
Supported RF protocols (TX): CRMX, W-DMX G3, G4S
Supported RF protocols (RX): CRMX, CRMX2, W-DMX G3, G4, G4S & G5
LEGAL
Thank you for buying a LumenRadio MoonLite
2
product. This guide is intended to give you a quick
CRMX and W-DMX are trademarks of LumenRadio AB.
DMX-512A and RDM refers to ANSI national standards developed and maintained by ESTA,
Entertainment Services and Technology Association.
This product makes use of US patents 7,432,803; 9,208,680; EU patents EP 2415317, EP 2803248,
China patents CN 102369774, CN 104041189B and others.
Scan for additional information
XLRs
USB-C
Navigation buttons
Power/ Back button
Expansion port
Charging case
interface (on the back)
Screen
