Cabinet
A ess mbly stru ti In c ons
W
O R C EK S P A S
www.luxorworkspaces.com
800-323-4656
Parts Key
D x 4
Thumbscrew
C x 2
Bolt,
Phil Headlips
A x 1
Charging Cabinet
B x 1
Cord Wrap
Tools Required:
Phillips Head Screwdriver
1Position cord wrap on the rear of
the cabinet, er the corresponding ov
threaded mount holes.
B
C
A
Rem e the rubber caps from ov
the top of the cabinet.
4
Inser eact h bolt into loa ck washer,
then a flat washer, then use to
attach the casters to the Dolly.
2
3
Rem e the drawer from the ov
botto n by m/l er cabiow et
pre ingss
the release lever on each side
of the drawer track.
Position a second cabinet on top,
aligning the threaded
mount holes.
5Using the thumbscrews attach the lower
Cabinet to the upper Cabinet.
6
D

A ess mbly stru ti In c ons
W
O R C EK S P A S
www.luxorworkspaces.com
800-323-4656
Parts Key
Tools Required:
Phillips Head Screwdriver
Caster,
Locking
A x 2
Caster,
Non-Lo ingck
B x 2
Bolt,
Phillips Head
C x 1 6
D x 1 6
Lock Washer
E x 1 6
Flat
Washer
F x 8
Thumbscrew
L PLMCD
Mo ul Chd ar arg g in
Cabi t –ne
Double Dolly
IMPORTANT: Position the locking casters on the
end next to the p er strip.ow
Flip the Dolly over and position the casters er the corresponding threadedov
mount holes.
1
A
B
Insert each bolt into a lock washer, then a flat
washer, then use to attach the casters to the Dolly.
2C
D
E
3Using the thumbscrews, attach the Modular Charging Cabinets.
IMPORTANT: Position the Charging Cabinets so the cabinet doors face
perpendicular to the edges of the Dolly with the p er strips.ow
F

1
W
O R K S P A C E S
www.luxorworkspaces.com
800-323-4656
LLMCDC
Modular Charging Cabinet
– Dolly Connection Plate
Assembly Instructions
Parts Key
Caster,
Locking
B x 4
Caster,
Non-Locking
C x 4
Bolt,
Phillips Head
D E x 3 2 x 3 2
F x 3 2
Lock Washer
Flat
Washer
G x 8
Thumbscrew
Tools Required:
Phillips Head Screwdriver
* Phillips head bolts come with the
Dolly assemblies.
** Thumbscrews come with the Modular
Charging Cabinet assemblies.
A x 1
Connection Plate
Flip the Dollies over, position them end-to-end with the power
strips facing out, and position the casters at each corner over the
corresponding threaded mount holes.
IMPORTANT: Position at least one set of locking casters on one end.
If desired, you can place a locking caster at all four corners.
2Position the Connection Plate over the corresponding
threaded mount holes where the two Dollies are joined.
Use the remaining 16 bolts to attach
Connection Plate to the Dollies.
4
Insert each bolt into a lock washer, then a flat washer,
then use 16 bolts to attach the casters to the Dollies.
3
IMPORTANT: Position the Charging Cabinets so the
cabinet doors face perpendicular to the power strips.
Using the thumbscrews, attach the
Modular Charging Cabinets.
5
F
F
A
B
C
D
E
F
D
E
F
