User Guide

User Guide User Guide

English ( 2 – 6 )

Guía del usuario

Guía del usuario Guía del usuario

Español ( 7 – 11 )

Guide d’utilisation

Guide d’utilisationGuide d’utilisation

Français ( 12 – 16 )

Guida per l’uso

Guida per l’uso Guida per l’uso

Italiano ( 17 – 21 )

Benutzerhandbuch

Benutzerhandbuch Benutzerhandbuch

Deutsch ( 22 – 26 )

Appendix

Appendix Appendix

English ( 27 )

MIC/LIN EMIC/LIN E

M-TRACK

2X2M

C -SERIES

User Guide ( )English

Introduction

Box Contents

BX5 D3

Power Cable

Acoustic Foam Pad

User Guide

Safety & Warranty Manual

Support

For the latest information about this product (documentation, technical specifications, system

requirements, compatibility information, etc.) and product registration, visit m-audio.com.

For additional product support, visit m-audio.com/support.

Setup

Connection Diagram

Items not listed under Introduction > Box Contents are sold separately.

Audio

Interface

Power

Features

Rear Panel

1. XLR Input: This jack accepts XLR input

connections with either balanced or unbalanced

wiring. The input wiring of an XLR connector

should be as follows:

• XLR Pin 1: signal ground (shield)

• XLR Pin 2: signal positive (+)

• XLR Pin 3: signal negative (–)

2. TRS Input: This jack accepts 1/4" (6.35 mm)

connections with either balanced or unbalanced

wiring. For balanced wiring, a three-conductor

TRS plug is necessary. The input wiring of a TRS

connector should be as follows:

• TRS Tip: signal positive (+)

• TRS Ring: signal negative (–)

• TRS Sleeve: signal ground (shield)

3. Acoustic Space Switch: Your BX5 D3 monitors

should ideally be placed at least one foot away

from the nearest wall, ceiling, or other large, flat

surface. However, this may be impractical due to

space limitations within your studio. For that reason, BX5 D3 monitors feature an acoustic

space switch. This switch compensates for placement near walls.

Tip: Be sure to leave at least 3" of space between the rear of the speaker and a wall to

allow the rear-firing port to "breathe" properly. Placing the speaker any closer than 3" may

adversely affect low-frequency response.

4. Sub-Frequency Vent Port: This port aids in reproduction of very low frequencies by

discharging frequencies below 60 Hz and to act as a cooling mechanism to prevent

overheating. This port should not be blocked.

5. Volume Control: Use the volume control to set the output from the BX5 D3 to proper

levels as required.

6. Power Switch: This switch turns the monitor on and off.

Note: This product does not have a standby/low-power mode.

7. Power Receptacle: Accepts a detachable 3-conductor IEC power cord in order to power

the monitor.

8. Fuse Holder: Holds the external main fuse.

9. Voltage-Select Switch: Provides two selections, 115V AC and 230V AC, and should be

set to match the "house supply" (receptacle) mains voltage of the country or location in

which the speaker is used. The 115V setting is correct for the USA, while the 230V setting

is correct for most of the UK and Europe.
