Sida 1/2
USER MANUAL
PoE Splitter with switchable output power
NW-PSSO-004
Mach Power® is registered trade mark / All Right Reserved
> visit our website www.machpower..it
INTERFACE DESCRIPTION
1
2
3
4
RJ-45 input Port (power+data)
Interchargeable tips (power out)
RJ-45 output port
Adjustable DIP switch (5V / 9V / 12V)
5
6
7
8
Wall-Mountable
PoE LED 5V (green)
PoE LED 9V (green)
PoE LED 12V (green)
PACKAGE CONTENT
x1
x1
x1
x1
x4
Poe Splitter
Quick Installation Guide
Network cable
DC Cable
Interchageable tip
Advanced PoE Solution
The PoE Splitter splits a networked PoE Signal into separated power and Gigabit data sources. This device
allows administrators to run Gigabit speed PoE cables over long distances and then split the PoE signal
into separated data and power sources in order to network non-PoE devices. Save installation and
equipment cost when installing 802.11n access points, (Pan/Tilt/Zoom) IP cameras and more in remote
locations. No need to install network devices near a power outlet. This compact device safeguards valuable
network equipment with short circuit protection and quickly creates an integrated PoE and non PoE network
at Gigabit speeds.
KEY FEATURES
• Network devices at 10/100Mbps all within a compact device
• Automatically detects PoE terminals and supplies inline power
• Easily install non-PoE devices where a power outlet is not available
• Reduce installation and network equipment costs
• Safeguards network device with short circuit protection
• Adjustable output DIP switch for 5V, 9V, and 12V adjustable output
• Converts Non-PoE devices with Power Over Ethernet Support
• Auto-sensing power drawn from 802.3af power source equipment(PSE) devices
• Supplies power up to 12.9 watts
• Provides Interchangeable tips
TECHNICAL SPECIFICATION
Standards Compliance
Diagnostic LEDs
Data Rate
Input Power Voltage
Output Power Voltage
Dimensions
Weight
Operating Temperature
Storage Temperature
Certification
IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-Tx Fast Ethernet
IEEE 802.3af Power over Ethernet
DC Power (Green)
RJ-45, 10/100 Mbps
Pin Assignment and Polarity: 1/2(+), 3/6 (-) or 4/5(+), 7/8(-)
5V (2A), 9V (1.1A), 12V (0.85A)
80mm x 55mm x 31mm
76g
0~45°C
95%, Non-condesing
RoHS Compliant, CE/FCC
