Oct 2013 • All questions, answers and speciﬁcations subject to change.www.mackie.com/support/

QUICK STEPS TO WIRELESS SUCCESS

Full instructions for wireless setup for the DL Series Mixers can be found in the Quick Start and

Reference Guide. But if you want to get up and running quickly by reading as few words as possible,

this document is for you.

1. DL1608 or DL806 Mixer

2. Wi-Fi router (please see page 24 of the Reference Guide for more information)

3. Ethernet cable

4. iPad (with Master Fader app installed)

5. Signal source to plug into the DL1608 or DL806 (microphone, iPod, string-quartet, etc.)

You will need the following in order to make your DL Series Mixers and Wi-Fi router work correctly.

We hope that this helps you with your questions. For more information regarding DL Series Mixers please refer to the

Quick Start or Reference Guide. These are both easily accessed directly from Master Fader by going to the Tools menu and

choosing the Help tab or by visiting the DL Series website.

Step 1: Unbox the DL Series mixer, plug the power cable into

the back of the mixer (plug it into the wall at this time as

well) and connect signal source. Do turn the mixer on NOT

at this time.

Step 2: Plug the Wi-Fi router into its power cable (plug it

into the wall at this time as well). Most of the default router

settings will work to connect to the mixer using Wi-Fi but you

might need to conﬁgure your wireless router before you can

connect to the DL Series hardware (please see the manual

for your speciﬁc router for information).

Step 3: Plug the Ethernet cable into the mixer and Wi-Fi

router. Make sure you are using a LAN port and not a WAN

port on the Wi-Fi router.

Step 4: Turn on the Wi-Fi router ﬁrst, wait for it to completely

boot up and then turn on the DL Series mixer.

Step 5: In the iPad’s Wi-Fi settings page, select the name of

the wireless network you created. This might be the default

name of the router or a custom name if you conﬁgured

the network setting on the router. Make sure the correct

network is selected.

Step 6: Slide the iPad into the dock of the DL Series mixer.

Step 7: Launch the Master Fader app assuming you have

already downloaded it from the App Store.

Step 8: If this is the ﬁrst time you connected to the

DL Series mixer, the mixer will go through a ﬁrmware

update upon boot-up. The ﬁrmware update can take up to

15 minutes. (If you have previously completed the ﬁrmware

update, move on to the next step.)

Step 9: Click the Gear icon to display the Tools menu and

choose the Devices tab.

Step 10: There should be three sections listed: Ofﬂine,

Wired and Wireless. At this point the Wired DL Series mixer

should be selected and you can leave the Tools menu and

start using the DL Series mixer hardware while docked. It is a

good idea to connect a microphone or another signal source

to ensure that you see channel meters and can control levels.

Step 11: Go back to the Tools menu and with the Devices

tab still open undock the iPad from the mixer and select

the Wireless DL1608 or DL806 from the devices list.

At this point you should now be able to control the DL1608

mixer wirelessly.
