O W N E R ’ S M A N U A L

Install Performance Loudspeakers

iP Series

iP Series Loudspeakers

Don’t forget to visit our website at www.720trees.com

for more information about this and other products.

Loudspeaker 1

Loudspeaker 3

Loudspeaker 2

Loudspeaker 4

Please write the serial number for your loudspeaker(s) here for future reference:

Purchased at:___________________________________ Date of Purchase:_____________

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliﬁers) that produce heat.

Only use attachments/accessories speciﬁed by the manufacturer.

10.

Use only with a cart, stand, tripod, bracket, or

table speciﬁed by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

11.

Refer all servicing to qualiﬁed service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged,

liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate

normally, or has been dropped.

12.

Exposure to extremely high noise levels may cause permanent hearing

loss. Individuals vary considerably in susceptibility to noise-induced

hearing loss, but nearly everyone will lose some hearing if exposed to

sufﬁciently intense noise for a period of time. The U.S. Government’s

Occupational Safety and Health Administration (OSHA) has speciﬁed

the permissible noise level exposures shown in the following chart.

According to OSHA, any exposure in excess of these permissible limits

could result in some hearing loss. To ensure against potentially danger-

ous exposure to high sound pressure levels, it is recommended that all

persons exposed to equipment capable of producing high sound pres-

sure levels use hearing protectors while the equipment is in operation.

Ear plugs or protectors in the ear canals or over the ears must be worn

when operating the equipment in order to prevent permanent hearing

loss if exposure is in excess of the limits set forth here:

PORTABLE CART

WARNING

WARNING — To reduce the risk of ﬁre or electric shock, do not

expose this apparatus to rain or moisture.

Duration, per

day in hours Sound Level dBA,

Slow Response Typical Example

8 90 Duo in small club

6 92

4 95 Subway Train

3 97

2 100 Very loud classical music

1.5 102

1 105 Troy screaming at Karl about deadlines

0.5 110

0.25 or less 115 Loudest parts at a rock concert

This symbol indicates that this product should not be disposed of with your household waste, according to the WEEE Directive

(2012/19/EU) and your national law. This product should be handed over to an authorized collection site for recycling waste electrical and electronic equipment (EEE). Improper handling

of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated with EEE. At the

same time, your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources. For more information about where you can drop off your waste

equipment for recycling, please contact your local city ofﬁce, waste authority, or your household waste disposal service.

Part No. SW1081 Rev. A 12/14

Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.

Apparatet må tilkoples jordet stikkontakt.

Apparaten skall anslutas till jordat uttag.

Owner’s Manual

iP Series Install Performance Loudspeakers are

designed exclusively for a wide range of installed

sound reinforcement applications. Behind each

iP loudspeaker’s clean, professional look are high-

output, custom-designed woofers and premium 1.4"

titanium diaphragm compression drivers delivering

rich, articulate full-bandwidth response. Ample rigging

points support vertical and horizontal rigging and a

choice of Neutrik® or terminal connections provides

install ﬂexibility. Optional ceiling and wall mounts are

available for aesthetically demanding venues. Plus,

the companion iP-18S 18" subwoofer is perfect for

additional low-frequency response and output in larger

applications. Add the SP260 speaker processor with iP

presets for quick setup and ﬂawless sonic performance.

Introduction

Contents

IMPORTANT SAFETY INSTRUCTIONS 2 ........................

CONTENTS 3 ..............................................................

INTRODUCTION 3 ......................................................

FEATURES 3 ...............................................................

HOW TO USE THIS MANUAL 4 ....................................

GETTING STARTED 4 ...................................................

THINGS TO REMEMBER 4 ...........................................

HOOKUP DIAGRAMS............................................... 5

PLACEMENT 7 ............................................................

ROOM ACOUSTICS 7 ..................................................

RIGGING 8 ................................................................

PROTECTION 10 ........................................................

AMPLIFIER POWER 10 ...............................................

RECOMMENDED POWER RATINGS 10 .........................

PREVENTING LOUDSPEAKER DAMAGE 10 ...................

APPENDIX A: SERVICE INFORMATION 11 ....................

APPENDIX B: CONNECTIONS ................................. 12

APPENDIX C: SPECIFICATIONS AND DIMENSIONS 13 ...

LIMITED WARRANTY 15 .............................................

Features

iP Full-Range Models:

• Low-proﬁle installation loudspeaker.

• High-output ceramic woofer with voice coil for

maximum output.

• iP-10 – 10" woofer / 2" voice coil

• iP-12 – 12" woofer / 2.5" voice coil

• iP-15 – 15" woofer / 2.5" voice coil

• 1.4" titanium compression driver provides smooth,

consistent high-frequency response.

• 8 × M10 rigging points and rotatable 90° × 50° horn

for vertical/horizontal rigging (PA-A2 accessory).

• Optional ceiling and wall mount accessories meet

the needs of the most aesthetically demanding

venues (iP-CM100 & iP-WM100 accessories).

• Rotatable center logo allows for clean presentation

in all conﬁgurations.

• Convenient terminal strip connectivity saves time

and cost.

• Dual Neutrik® parallel connectors.

• Lightweight, compact and durable 15mm poplar

cabinet construction.

• Companion iP-18S 18" subwoofer extends

low-frequency response and increases output

in larger applications.

• Optional SP260 2 × 6 speaker processor delivers

iP presets to get your system quickly dialed in.

iP-18S Subwoofer:

• 18" high-output installation subwoofer.

• 18" high-output ceramic woofer with 3" voice coil

for maximum output.

• Convenient terminal strip connectivity saves

time and cost.

• Dual Neutrik® parallel connectors.

• Lightweight, compact and durable 15mm poplar

cabinet construction.

• Optional SP260 2 × 6 speaker processor delivers

iP presets to get your system quickly dialed in.
