E-Control
User- and installation manual
Dated March 1
st
2004
Important:
Switch off power before connecting or disconnecting wiring to thermostat.
A qualified electrician to current IEE regulations must install all wiring, failure to do so may invalidate
the warranty.
Introduction:
The ME-control thermostat is very user friendly and has intelligent software to guide the user
throughout the whole menu-structure. The thermostat is capable of switching your underfloor heating
system on and off, up to four different times of the day. The ME-control has an automatic Setback
period. The setback periods are the events between your comfort periods. This will lower your room
temperature as well as your energy costs without reducing the comfort.
In order to program just follow the onscreen information, you will be guided through the different
menus and functions automatically.
Nevertheless it is strongly recommended to study the operators manual carefully and keep it for future
reference.
The ME-Control has a 3-button structure:
Middle button : Selection button, higher/lower and Scroll through options.
Right button : to confirm choices/settings and to proceed.
Left button : to rectify wrong choices and settings.
* Some menu parts contain more program choices than displayed at first sight. Use middle
button to scroll down until “Back to main Screen” is displayed, this is always the last choice in
all menus.
Start up menu:
When switching the thermostat on for the first time, you will be asked a series of questions about your
heating system.
1. Language - you have a choice between English, German & French
2. Date - set to present date
3. Time - choose between 12 & 24 hr clock, then set to present time
4. Heating system - choose “with floor sensor”
5. Floor thickness - Enermat (floor adhesive & tiles) or Enercable (<5cm, <10cm or >10cm)
6. Standard settings - Factory preset settings, can be changed in later menus.
7. Comfort temperature - Factory setting 21.5°C, change now or later in menu.
8. Select timer menu - only for new floors. Please allow for drying out period.
9. Timer - set for when floor is completely cured.
The menu-structure is provided with 3 main programs:
Start-up menu : to program factory or change settings.
Mode : to change settings temporarily
Menu : to change settings permanent
The auto standard comfort period factory settings:
Monday till Friday : comfort heating during 06.00 till 09.00 and 15.00 till 22.00 hrs.
Saturday and Sunday : comfort heating during 09.00 till 23.00 hrs.
Besides the above-mentioned periods the thermostat works on stand-by and is auto-programmed for
lower setback temperatures to save energy consumption.
Explanation of the LED colors and signals :
Yellow : Heating system is operational. No energy consumption.
Red : Active energy consumption. System in heating mode.
Green : Heating system in setback period.
Red flashing fast : Sensor failure.
Heating system non-operational (Please contact Technical Support).
Red flashing slowly : Heating system in sleeper function
will be activated by timer at mentioned date/time.
Explanation main screen textures:
Comfort period : heating system operational
Setback : setback period activated
Heating : power on
Timer activates on : date and time of activation of the heating system
Thermostat off : heating system not operational
Manual control : auto-standard settings off - manual temperature adjustment +/-
Sensor failure : heating system non-operational
At the same time, the appearance of main-screen is the confirmation that all standard settings or pre-
programmed settings are fully operational.
Use the auto-program as confirmed in Start menu approx. 14 days after date of activation. In this way
the memory of the thermostat is able to store and adapt historical temperature movements.
Important:
Changing standard settings is only possible from main screen, by using Mode (left button) and Menu
(right button)
Press the Mode button for temporary changes and the Menu button for permanent changes in
standard settings.
Always return to main screen after new settings are programmed.
Press Mode for temporary changes and next options appear in display:
Options Explanation
1. Temporary temperature : Used only when thermostat is in setback mode and extra heating
is required.
2. Thermostat Auto : Thermostat will follow factory settings or 7 days program.
3. Manual Control : The thermostat will heat continuously 24/7 according to the comfort
temperature.
4. Thermostat OFF : Thermostat is turned off and will not follow any program, however all
presets remain in memory.
5. Timer : Timer menu is used when there will be no heat requirement for a
long period of time, for example during holidays.
This is also used when new floors are installed, to allow a drying out
time and avoid possible construction damage because of early
heating.
6. Back to main screen : Return to main screen.
Scroll to option and press confirm to activate one of the above.
