Sida 1/6
r’s
al
Photo Tripod
PV-7451M
Overview
Thank you for choosing Magnus.
The Magnus PV-7451M Tripod employs an adjustable
center column that converts to a four-section
monopod for enhanced flexibility. Telescoping legs
with flip-locks offer fast and easy adjustments, with
enclosed spiked feet for all-terrain shooting. The three-
way pan and tilt head offers total control over camera
positioning, and the quick-release plate is equipped
with a 1/4”-20 male thread for universal camera
mounting.
Please read and follow these instructions and keep this
manual in a safe place.
Monopod leg
sections
Enclosed
spiked feet (×3)
Leg flip-locks (×6)
Mid-level spreader
Spreader lock
Center column/
monopod
Center-column
locking knob
Panning marks
Pan handle
Pan handle
twist-lock
Pan locking
knob
Friction control knob
Platform orientation
locking knob
Quick-release lever
Bubble levels (×2)
Quick-release
mounting plate
Video register pin1/4-20 mounting screw
Opening the Tripod
1
Loosen the pan handle
and position it at an
approximate 90° angle
to the center column.
2
Pull out each flip-lock,
extend the legs to the
desired height, and
relock each leg.
Note: Always
extend the legs from the top flip-locks first.
3
Rotate the spreader
lock counterclockwise to
release the center brace.
Gently pull the legs out
to the open position and
rotate the spreader lock clockwise until secure.
Using the Enclosed Spiked Feet
When setting up on soft ground, the spiked feet can
provide more stability.
To expose the spikes,
rotate the tripod feet
clockwise. To enclose the
spikes, rotate the tripod
feet counterclockwise.
Mounting Your Camera
1
Pull and hold the quick-release plate locking lever
to release the plate. Lift
the plate up and out.
2
Align the quick-release
plate lengthwise with the
bottom of your camera.
If you’re using a video
camera, make sure the
video register pin is
aligned with your video
camera’s pin socket.
3
Insert the plate’s
mounting screw into
your camera’s tripod
socket and fasten
the screw using the
screwhead handle until fully tightened.
