Sida 1/78
LDX1
INSTRUCTION MANUAL
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Laser Receiver
1x Receiver ON
2x Illumination ON
3x Illumination OFF
3sec OFF
+/- 1mm
Sensitivity:
+/- 3mm
Beep HIGH
Beep MEDIUM
Beep OFF
full
low
Insert batteries:Overview:
Attach bracket:
Operation:
EN
Makita LDX1
D
GB
F
I
E
P
NL
DK
S
N
FIN
J
CN
RC
ROK
PL
HR
H
RUS
CZ
GR
LT
LV
EST
SLO
SK
M
TR
Operating Instructions
Operating Instructions
The Makita LDX1 is a robust and easy to use laser receiver and
can be used with all Makita line lasers with red and green laser
diodes, to detect horizontal and vertical laser lines.
Overview
Technical Data
Introduction
The safety instructions (see Safety Instructions) and the user
manual should be read through carefully before the product is
used for the first time.
The person responsible for the product must ensure that all users
understand these directions and adhere to them.
The symbols used have the following meanings:
WARNING
Indicates a potentially hazardous situation or an unintended use
which, if not avoided, will result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation or an unintended use
which,if not avoided, may result in minor injury and/or appreciable
material, financial and enviromental damage.
Important paragraphs which must be adhered to in practice
as they enabled the product to be used in a technically correct
and efficient manner.
Alkaline batteries
To ensure a reliable use, we recommend using high quality
Alkaline batteries.
Storage
Alkaline batteries
If the equipment is to be stored for a long time, remove the alka-
line batteries from the product in order to avoid the danger of
leakage.
Cleaning and drying
Product and Accessories
• Blow dust off optical parts.
1
Beeper
7
Detection window
2
Front display
8
Beeper key
3
ON / OFF / Illumination key
9
Bracket thread
4
Accuracy key
AT
Magnets
5
Spirit level
AK
Back display
6
Reference notch
AL
Battery compartment
Working range (depending
on lightning conditions)
2 m – 80 m (6.6 ft – 262 ft)
Accuracy (switchable) ±1.0 mm (±0.04 in) /
±3.0 mm (±0.12 in)
Detection window 85 mm (3.3 in)
Detectable spectrum 635 nm ±5 nm red / 525 nm ±5 nm green
Class 2 in acc. 60825-1
Automatic shutoff 30 min without detection
Illuminated display Front side and back side
Accustical signal 100 dB / 80 dB / 0 dB
Protection class IP65 (IEC 60529)
Battery type/life 2 x AA 1.5 V / 40+ hours
Dimensions (LxWxH) 158 x 73 x 26 mm ( 6.22 x 2.87 x 1.02 in)
Weight with batteries 250 g (0.55 lbs)
Operating temperature -10 - +50 °C (+14 - +122 °F)
Storage temperature -25 - +70 °C (-13 - +158 °F)
