40VMAX BRUSHLESS

305MM SLIDE

COMPOUND MITRE

SAW XGT

LS003GD201

Model LS003G is a large-size 305mm slide compound mitre

saw powered by 40Vmax XGT Li-Ion battery and equipped

with a brushless motor that provides consistently smooth

cutting

TECHNICAL SPECIFICATIONS

Battery TypeLithium-ion

Voltage40 v

Blade Diameter305 mm

Bore Diameter30 mm

No Load Speed3,600 rpm

Max bevel range48 - 48 º

Max mitre range60 - 60 º

Noise sound pressure91 dB(A)

Noise sound power100 dB(A)

Noise K factor3 dB(A)

Net weight30.5 - 31.1 kg

Link to product - makitauk.com

USER BENEFITS

•LED lamp casts a shadow of the saw blade onto the

workpiece as an exact cutting line

•Electric brake

•Smooth cutting

•High precision cut

•Auto-Start Wireless System (AWS) - connects to

compatible dust extractors with Bluetooth. The dust

extractor automatically runs while the switch is on.

•Rail-forward design: allows the rear of the machine to

be placed close to the wall

•Constant speed control

•Soft start

•Large turn base

•Sub base supports a wide workpiece

•Positive stop function can be disabled simply by

depressing a lever

•Easy locking and release of bevel angle

•Switch to start up dust extractor (via bluetooth

technology)

•Improved dust extraction

LS003GD201LS003GD201LS003GD201LS003GD201 - 40VMAX BRUSHLESS 305MM SLIDE COMPOUND MITRE SAW XGT

Page 1(2)

makitauk.com

5-3-2022
