USB-C to HDMI Converter with Power

Delivery Port

4K@60Hz Resolution, Power Delivery up to 60 W (20 V / 3 A), Black

Part No.: 153416

EAN-13: 0766623153416 | UPC: 766623153416

Our USB-C to HDMI Converter with Power Delivery

(PD) Port: UHD HDMI from your device's USB-C port

and power for all devices

The Manhattan USB-C to HDMI Converter with PD Port lets you easily show

content from your USB-C-equipped device on an existing HDMI display, monitor

or projector. This converter is easy and quick to install — no settings

or adjustments required. It is a compact yet powerful solution that helps avoid

extra cables, tangles and clutter to keep workspaces neat and tidy.

USB-C Power Delivery

The included USB-C PD port gives up to 60 W (20 V / 3 A) to all devices in your

setup. Connecting the upstream device’s cable and adapter supplies power to

the upstream device and boosts the 4K signal to your display for the perfect

picture. The PD function also provides faster charging than standard chargers

since it finds out the power needs of compatible devices and supplies it at the

quickest and safest rate.

Features:

Supports resolutions up to 4K@60Hz following HDMI 2.0 standards

Supports Power Delivery (PD) up to 60 W (20 V / 3 A)

Supports USB Power Delivery (PD) function up to 60 W; requires an

external PD charger – available from Manhattan

Thunderbolt 3 compatible

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Compliant with DisplayPort 1.2 Alternate Mode (DP Alt Mode)

Plug and Play; requires no external power supply

Fully shielded to reduce EMI and other interference sources

Molded PVC boot and strain relief

Lifetime warranty

Specifications:

Standards and Certifications

• USB 3.2 Gen 1

• DP 1.2 Alternate Mode

• PD 3.0

• HDMI

• HDCP 2.2

• CE

• FCC

• RoHS2

• WEEE

Connections

• USB type C, 24-pin, male

• HDMI, 19-pin, female

• Power Delivery USB-C port

Video Resolutions

• 4K@60Hz

• 4K@30Hz

• 1080p

• 720p

• 1024x768

• 800x600

• 640x480

Physical

• 32-AWG cable gauge

• Mylar and aluminum shielding

• Thermal plastic casing

• Dimensions: 60 x 40 x 16 mm (2.36 x 1.57 x 0.63 in.)

• Cable length: 19.5 cm (7.67 in.)

• Weight: 31.76 g (1.12 oz.)

• Shielded

• Housing: ABS plastic

Operating Environment

• Operation Temperature: 0 – 50°C (32 – 122°F)

• Storage Temperature: -40 – 85°C (-40 – 185°F)

• Humidity (noncondensing): 0 – 96%

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

System Requirements

• Windows XP/Vista/7/8.1/10

• Mac 9.x/10.x or above

• Android

Package Contents

• USB-C to HDMI Converter with Power Delivery Port

• Quick Instruction Guide

This product is part of a group; the complete list of variations follows:

• #153690 - USB-A to HDMI

• #151788 - USB-C to HDMI, 4K@30Hz

• #153416 - USB-C to HDMI, 4K@60Hz, PD Port

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Produktspecifikationer

Varumärke:	Manhattan
Kategori:	Nätverkskort/adapter
Modell:	153416
Vikt:	31.76 g
Bredd:	60 mm
Djup:	40 mm
Höjd:	16 mm
Antal HDMI-portar:	1
Certifiering:	CE\nFCC\nRoHS2\nWEEE
Uteffekt:	3 A
Värdgränssnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Hub-gränssnitt:	HDMI
Kabellängd:	0.195 m
Produktens färg:	Svart
bruksanvisning:	Ja
Antal per förpackning:	1 styck
Windows-operativsystem som stöds:	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP
Mac-operativsystem som stöds:	Ja
Andra operativsystem som stöds:	Android
USB-strömförsörjning upp till:	60 W
Temperatur vid drift:	0 - 50 ° C
Temperaturintervall (förvaring):	-40 - 85 ° C
Intervall för relativ operativ luftfuktighet:	0 - 96 %
Utgångsspänning:	20 V
Material, hölje:	Akrylnitrilbutadienstyren (ABS)
Minsta drifttemperatur:	0 ° C
Maximal arbetstemperatur:	50 ° C
Plug & Play-kompatibel:	Ja
Harmonized System (HS)-kod:	84733020
Faktisk dataöverföringshastighet:	- Mbit/s
Antal anslutningar:	2
Nätaggregatstyp:	USB
Omgivningstemperatur vid drift:	32 - 122 ° F
AWG kabelstorlek:	32
USB-strömleverans:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1)typ C-portar:	1
Revision av USB-strömförsörjning:	3.0
Högsta upplösning (HDMI):	3840 x 2160 pixlar
