Sida 1/4

SuperSpeed USB-C to 7-in-1 Docking Station

USB 3.1 Type-C Male to HDMI, Mini DP or VGA, Three USB 3.0 Type-A Ports, USB-C

PD Port, Gigabit RJ45 Port, SD Card Reader, and 3.5 mm Audio Port; Aluminum,

Gray

Part No.: 152808

Easily connect a USB Type-C device to an HDMI, Mini DP or VGA display, USB

peripherals, Network and SD memory card.

The Manhattan SuperSpeed USB-C to 7-in-1 Docking Station establishes a fast, simple

and convenient link between newer USB Type-C-equipped media sources (computers,

tablets, Smartphones, etc.) and an existing HDMI/Mini DP/VGA display (monitors,

projectors, etc.), in either mirror- or extended-display mode. Create a mini-workstation by

adding any USB 3.0 (and earlier) peripheral, such as a mouse, keyboard, hub, external

memory device and more, with the integrated USB-A ports, Gigabit network connection,

3.5 mm Stereo and SD and Micro SD card slot, all while charging your device through the

USB-C port.

The Manhattan SuperSpeed USB-C to 7-in-1 Docking Station is easy and quick to install.

No complicated configuration or setup is required to enhance the functionality of your

Type-C device. Its all-in-one design achieves a compact, integrated solution that eliminates

unnecessary cables, tangles and clutter to keep installations and work spaces neat and

orderly.

Features:

Multi-function docking station connects a USB Type-C device to an HDMI, Mini DP or

VGA display, three USB 3.0 Type-A ports, a 10/100/1000 Mbps port, a 3.5 mm stereo

port, a USB-C power port and an SD Card Reader

Delivers Ultra-High-Definition (UHD) 4K@30Hz video and audio over HDMI or Mini

DP connection or HD 1080p video over VGA connection

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Mirror or extended-display modes support video resolutions up to 1080p@60Hz or

3840x2160 at 30 Hz (4K) Full UHD; Mac only supports mirror mode

One Gigabit Ethernet (10/100/1000) port for faster downloads, media streaming and

gaming

Three USB 3.0 Type-A ports to connect mice, keyboards or portable memory devices

(and more) or to charge and sync a portable electronic device

USB-A SuperSpeed ports offer 5 Gbps data transmission speeds; BC1.2 port charges

up to 7.5 W (5 V / 1.5 A)

Easy access to media and content management with read/write/copy Micro SD and

SD slots; supports automatic card detection and data transfer speeds up to 90 Mbps

USB-C Power Delivery (PD) port for a maximum of 60 W (20 V at 3 A) to connected

devices

USB-C port provides 5 Gbps data transmission

3.5 mm jack for high-quality stereo sound; both mic (audio input) and headphone

(audio output)

Aluminum housing makes this durable converter the perfect desktop or travel

companion

Compatible with all USB-C DP-Alt-Mode-supported desktops, notebooks and tablets

including Apple MacBook, Chromebook, Pixel and more

Compliant with DisplayPort 1.2 Alternate Mode (DP Alt Mode)

Plug and Play

Fully shielded to reduce EMI and other interference sources

Molded PVC boot and strain relief

Three-Year Warranty

Specifications:

Standards and Certifications

• USB 3.1

• HDMI

• HDCP 1.4

• CE

• FCC

• RoHS2

• WEEE

General

• Video Resolutions: 640 x 480, 800 x 600, 1024 x 768, 1920 x 1200, 1080p, 3840 x 2160p

at 30 Hz, 4K

• USB-A ports: 5 Gbps

• Supported flash cards: SD / SDHC / SDXC / EXTREME SD / EXTREME II SD /

EXTREME III SD / ULTRA SD / ULTRA II SD / ULTRA II SD P PLUS / SD-ULTRA-X /

ULTRA SPEED SD / SD PRO / SD ELITE PRO / HS SD / MMC / MMC 4.0 / HS MMC / HS

RS MMC / RS MMC / RS MMC 4.0 / MMC Mobile

• Supported flash cards: SD, SDHC and SDXC; up to 128 GB

Transfer speed: up to 90 Mbps

• 34-AWG cable gauge

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Produktspecifikationer

Varumärke:	Manhattan
Kategori:	USB-hubb
Modell:	162746
Vikt:	90 g
Bredd:	38 mm
Djup:	89 mm
Höjd:	10 mm
Certifiering:	CE, FCC, WEEE, RoHS2
Uteffekt:	1 A
Snabbinstallationsguide:	Ja
Värdgränssnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Hub-gränssnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Kabellängd:	0.2 m
Produktens färg:	Svart
Förpackningstyp:	Blåsa
Antal per förpackning:	1 styck
Inbyggd kortläsare:	Nej
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	5 - 90 %
Utgångsspänning:	5 V
Material, hölje:	Akrylnitrilbutadienstyren (ABS)
Kabel inkluderad:	USB Type-C
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	4
Plug & Play-kompatibel:	Ja
Linux operativsystem som stöds:	Ja
Harmonized System (HS)-kod:	84719000
Faktisk dataöverföringshastighet:	5000 Mbit/s
Antal anslutningar:	4
Byte under drift (hotswap):	Ja
AWG kabelstorlek:	24
