Sida 1/2

VGA C 5/5at e/6

EXTENDER

RECEIVER

REFERENCE

GUIDE

Model 177245

Thank you for purchasing the

MANHATTAN® VGA Cat5/5e/6

Extender Receiver, Model 177245.

By extending VGA and audio signals

using Cat5/5e/6 cables for longer

distance transmissions, this handy

device helps provide you with more

convenient placements from a single

source to another display.

MH-177245-QIG-0908-03

All products mentioned are trademarks or registered trademarks of their respective owners.

MANHATTAN® offers a complete line of PC Components, Peripherals, Cables and

Accessories. Ask your local computer dealer for more information or visit us online at

www.manhattan-products.com

Standards/Certications

• FCC, CE

General

• Transmission range:

up to 300 m

• Resolution supported: up

to 1920 x 1200; VGA,

SVGA, Multisync signal

types

• Manual adjustments:

Gain, Peak

• Power adapter: 5 V DC /

2 A

Connections

• HD15 female (output)

• RJ45 female (input)

• 3.5 mm stereo jack

(audio out)

• 5 V DC power port

Video Signal Input

• Signal type: VGA

• Connection type: RJ45

interface input

• Input voltage: 0.5 V p-p /

2.0 V p-p (min./max.)

• I/O impedance: 75 Ohms

Video Signal Output

• Signal type: VGA

• Connection type: HD15

female interface output

• Min./max. input voltage:

0.5 V p-p / 2.0 V p-p

• I/O impedance: 75 Ohms

Physical

• Dimensions: 81.5 x 43 x

23 mm (3.2 x 1.7 x 0.9 in.)

• Weight: 108 g (3.8 oz.)

• Housing: metal

Package Contents

• VGA Cat5/5e/6

Extender Receiver

• 5 V DC power adapter

• Reference guide

• Extends transmission range up to

300 m

• Supports resolutions up to

1920 x 1200

• Delivers a sharp, clear signal

with Gain & Peak adjustments

• Easy installation: No software

required!

• Requires MANHATTAN Splitter/Extender

Transmitter, Model 177252

• Lifetime Warranty

SPECIFICATIONS

See back page for

connection details.

rECEiVEr inpUt

rECEiVEr oUtpUt

OPERATING GUIDELINES:

•Alwaysmakesuretheproperpowersupplyisbeingusedbefore

installation or operation.

•Usematchedcabletoavoidimproperoperationordamage.

•Ensureunitsarewellventilatedandawayfromexcessiveheatand

humidity/moisture.

•Neveropenthedevice(s)withoutprofessionalassistance.

CONNECTIONS:

•ConnecttheUTPInput(RJ45)totheUTPOutput(RJ45)onthe

MANHATTAN Splitter/Extender Transmitter, Model 177252 using

 Cat5orCat6cable(notincluded).

•ConnecttheVGAOutputtotheremotedisplay.

•ConnecttheAudioOuttotheremoteaudiodevice(speakers,

 headphones,etc.).

•ConnecttheincludedpoweradaptertotheDC/5Vjack,thenplug

the adapter into an AC outlet.

•CheckthatthePowerLEDislit(nexttotheUTPInput(RJ45)jackto

 conrmthatthedeviceisoperational.

•AdjusttheGainandPeak(locatedonthesideofthereceiver)levels

as desired.
