Model
JC-0495
JC-0895
JC-1395
2110 South 26th Street
PO Box 1720
Manitowoc, WI 54221-1720 USA
Tel: 1.920.682.0161
Fax: 1.920.683.7589
www.manitowocice.com
Vertical Discharge Remote Condenser
For S-Series Ice Cube Machines
Vertical Discharge Remote Condenser
For S-Series Ice Cube Machines
JC-0895
Remote Condenser
Standard Features
•Vertical discharge remote condenser is available
for S-Series 500, 600, 850, 1000, 1400 and 1800
ice machines. Refer to ice machine specification
sheet for equipment dimensions, production
capacities, electrical requirements, and ice storage
bin compatibility.
•Condenser operation range from -20°F (-29°C) to
120°F (49°C). Can be installed with up to 20" (50.8
cm) of bottom clearance.
•Remote system consists of a remote condenser
and interconnecting refrigerant lines. All
components are pre-charged with environmentally
responsible refrigerant and have quick-connect
fittings for convenient installation. Order ice cube
machine, ice storage bin and line set separately.
Warranty
•3-year parts and labor. See warranty statement for
complete details.
Remote, air-cooled condenser system
improves efficiency and ice production,
conserving energy.
Manitowoc remote condenser systems
effectively dissipate heat at a convenient
location, indoors or outdoors, away from
the ice machine. This maximizes ice-making
capability and minimizes air conditioning
loads by lowering the ambient air
temperature at the ice machine.
Single S-Series
Ice Machine
Remote
Condenser
S-500JC-0495
S-600, 850 or 1000JC-0895
S-1400 or 1800JC-1395
Installation Information and Dimensions
Maximum Location Distance—combined vertical and horizontal
distances from ice machine to condenser must comply with guidelines.
Maximum Line Length: 100' (30 m)*
Maximum Vertical Rise: 35' (10.5 m) above ice machine.
Maximum Vertical Drop: 15' (4.5 m) below ice machine.
To calculate other acceptable horizontal and vertical combinations,
refer to remote condenser installation instructions.
* Remote condenser has refrigerant charge for up to 50' (15 m) line length.
Over 50' (15 m) requires additional refrigerant charge at time of installation.
