2110 South 26th Street
PO Box 1720
Manitowoc, WI 54221-1720 USA
Tel: 1.920.682.0161
Fax: 1.920.683.7589
www.manitowocice.com
RFS-0300 Flake Ice Machine
RFS-0300 Flake Ice Machine
Model
RFS-0300A
UL STD 563
CAN/CSA-C22.2 No. 120
SANITAT ION
NSF/ANSI STD 12
Standard Features
Up to 384 lbs. (174 kgs) daily
flake ice production.
Now in standard measurements for perfect
pairing with 22" ice bins. No adapter needed.
Service updates facilitate installation and
make cleaning easier.
Energy Improvements with RFS models
averaging 5% across the line.
Heavy duty stainless steel cabinet resists
corrosion.
Warranty
3-year Parts.
2-year Labor.
Compressor parts for 5 years
and labor for 2 years.
Model RFS-0300A
Flake Ice Machine
on B-420 Bin
Ice Machine Electric
115/60/1 standard. (230/50/1 also available.)
Minimum circuit ampacity:
12.8 amps.
Maximum fuse size:
20 amps.
HACR-type circuit breakers can be used
in place of fuses.
Specifi cations
Condenser Heat of
Rejection
(BTU per hour):
5,000 (average)
Compressor:
Nominal rating: 1/2 HP
Refrigerant:
R-404A
Operating Limits:
Ambient Temperature Range:
50˚-110˚F (10˚-43˚C)
Water Temperature Range:
37˚-90˚F (3˚-32˚C)
Water Pressure Ice Maker
Water In:
Min. 14 psi (96.5 kPA)
Max. 80 psi (551.1 kPA)
Ice Shape
Flake ice is small
hard bits of ice
ideally suited
for presentation
applications.
Ice shown actual size
Flake ice is small
Ice shown actual size
