LIMITED WARRANTY

Markbass oers an international limited warranty on Markbass products purchased from any

authorized Markbass dealer, eective from the day of purchase. The terms of this warranty

vary from country to country; please contact the Markbass distributor in your country for

details.

Please register this product online at www.markbass.it to establish the date of purchase.

However, please note that you are required to retain a copy of your receipt as proof of

purchase in order to receive warranty service.

This warranty does not apply to any damage to the product caused by misuse, mishandling,

accident, abuse, alteration, modication or unauthorized repairs. Product appearance and

normal wear and tear (worn paint, scratches, etc.) are not covered by this warranty. Markbass

reserves the right to be the sole arbiter regarding the misuse or abuse of this product.

Markbass assumes no liability for any incidental or consequential damages, which may result

from the failure of this product. Any warranties implied in fact or by law are limited to the

duration of this express limited warranty. Your legal rights related to the warranty will vary

depending on the country of purchase.

WARRANTY CARD

This product is guaranteed by the warranty provided in the country of purchase, under the

following conditions:

A - The Markbass warranty is only applicable if this document been properly completed (here

or online) and if the original invoice/bill of sale, mentioning model, serial number and

purchase date, is presented together with this document.

B - The obligations of Markbass are limited to the repair of defects. Warranty repair eligibility

will be decided at the sole discretion of Markbass or its representatives. Freight, freight

insurance costs, and any other costs related to the repair of this product are not covered by

this warranty.

C - All warranty repairs must be made by Markbass or an authorized Markbass (PARSEK)

service center.

D - This warranty does not apply in the following instances:

• if the damage was caused by accident, negligence or modications; use of non Markbass

spare parts; or improper use, installation or packing;

• if the serial number on the equipment is illegible;

• if the damage was caused by lightning, water, re, incorrect main voltage, insuﬃcient

ventilation or any other cause beyond the control of Markbass.

E - Markbass reserves the right to redesign or improve/modify its product at any time without

any obligation to modify previously manufactured products.

Parsek srl. - Italy - 66020 San Giovanni Teatino (Ch) - Via Po, 52/A Tel. +39 085 446 37 55 - Fax

+39 085 440 77 64 - www.markbass.it - info@markbass.it

GETTING STARTED

BOOST - To set up the Level Boost, plug your instrument into the Input Jack (5), and

connect the Output Jack (6) to your amplier, after connecting a +9/+12VDC power

supply to the DC IN to the DC IN (7). Turn the boost on using the footswitch (3), making

sure the LED (4) is ON (this indicates that the eect is active). Next, adjust the Boost

Level slider while toggling the footswitch (3) on and o, comparing the volume of the

direct signal with the boosted signal. Match the gain level as closely as you can to the

direct signal, then adjust the Level Boost slider to the desired amount of added boost

or cut. A suggested use of the boost is to leave it turned o until it’s time to solo, then

switch it on (3) for a quick level boost when you begin your solo. You can easily apply

this to ANY situation where you need two dierent, quickly accessible playing volumes.

VPF (Variable Pre-shape Filter) - This lter boosts lows and highs, and cuts mids.

Some call this kind of eect a scoop, a smiley-shape EQ, or an enhance knob. It’s very

eective for slap bass, pick playing, and driving eighth-note rock. It’s o when it is all

the way counterclockwise—we suggest you start in that position and turn the lter up

gradually, to hear and understand what it does.

TECHNICAL SPECS

INPUT IMPEDANCE: 1 Mohm / 6 Vpp

OUTPUT IMPEDANCE: 470 ohm / 6 Vpp

BOOST: 0 to +20dB (maximum gain)

POWER REQUIREMENTS- DC INPUT: +9/+12VDC

DIMENSIONS: 48.4 x 38.2 x 104.2 mm

1.91” x 1.5” x 4.1”

WEIGHT: 174 g

0.38 lbs

BLOCK DIAGRAM

booster

Level VPF

Out

OWNER’S MANUAL
