Sida 1/20
2002-1612 • XCAM2
WIRELESS
XCAM2
OWNER’S MANUAL 3
BETRIEBSANLEITUNG 7
MODE D’EMPLOI 11
GEBRUIKSAANWIJZING 15
A
B
C
I
D
E
FGH
2 MARMITEK
WIRELESS
XCAM2
ENGLISH
OWNER’S MANUAL
READ THIS FIRST!
Caution: to reduce risk of electric shock, do not disassemble any part of the videosender system.
No user-serviceable parts are inside. If you spill liquid on it, disconnect the unit from the AC outlet
to prevent possible fire or shock hazard and consult authorized service personnel.
Mains operated equipment or accessories connected to the unit should carry the CE certification
mark and should not be modified in any way that might overwrite the safety features.
Warning: To prevent electric shock hazard, do not expose any part of the power supplies to rain
or moisture. Do not use near a bath tub, swimmingpool, etc. The camera is rated IP53, Secure
against direct rain falling vertically. To rain driven by wind at 30˚ from the horizontal.
APPLICATIONS:
Using the Marmitek wireless XCAM2 provides convenience and security in many ways:
• Watch your frontdoor on any TV in your home without running cables.
• Watch your baby’s rooom on any TV anywhere in your house.
1. HOOKING UP THE MARMITEK XCAM 2 CAMERA:
1. Attach the camera to a suitable wall. If using outdoors remember to make a small hole to
enable the power lead [C] to pass through.
2. The camera is suitable for outdoor use (IP rating 53)
3. When using outdoors, fix in place the clear plastic lens cover (supplied)
4. Use the smaller of the two power supply`s (marked transmitter) and plug the jack into the
adaptor socket on the lead from the camera.
5. Connect the power supply to the mains and switch on.
6. Adjust the antenna [A] until optimum picture quality is reached on the receiving TV.
Only use the supplied mains adaptor!
2. HOOKING UP THE MARMITEK XCAM2 RECEIVER:
1. Connect a set of Audio/Video cables to the LINE OUT jacks [H+G] of your GigaVideo Receiver.
Connect the other end to your TV.
2. Plug the supplied mains adaptor, labelled Receiver 500mA, into a 230Volt -50Hz wall outlet
and connect the jack [E] to the 12V jack at the rear of the receiver.
Only use the supplied mains adaptor!
3. Switch the Power switch [E] to the ON position.
4. Select the right channel
Look for the corresponding channel with your camera by switching the channel slide switch at
the bottom of the receiver [I] (camera channel may be changed by removing the rubber cover
on the front of the camera base [B]). Receiver and camera should be set to the same channel.
3XCAM2
