Martin Audio – MA200Q Amplifier
ENGLISH
1
CONTENTS (ENGLISH) Page No
1 CONTENTS MA200Q USER GUIDE 1
2APPROVALS 2
3WARNINGS 2
3.1 EXPLANATION OF GRAPHICAL SYMBOLS 2
3.2 WARNING 2
3.3 CAUTION 2
3.4 IMPORTANT SAFETY INSTRUCTIONS 2
3.5 USER RESPONSIBILITY 3
3.5.1 LOUDSPEAKER DAMAGE 3
3.5.2 LOUDSPEAKER OUTPUT HAZARD 3
3.5.3 RADIO INTERFERENCE 4
4 INTRODUCTION 4
4.1 UNPACKING 4
4.2 FRONT PANEL 4
4.3 REAR PANEL 5
5 REAR PANEL FEATURES 6
5.1 GAIN 6
5.2 SENSITIVITY 6
5.3 LINK SWITCH 7
5.4 OPERATING MODES 7
5.4.1 STEREO MODE 7
5.4.2 NOTES FOR AMPLIFIER TESTING 7
5.4.3 TANDEM MODE 8
5.4.4 BRIDGE MONO MODE 8
5.4.5 BRIDGE MONO MODE FEATURES 8
6 INSTALLATION 9
6.1 MOUNTING 9
6.2 COOLING 9
6.3 OPERATING VOLTAGE 9
6.4 GROUNDING 10
6.5 POWER CONSUMPTION 10
6.5.1 CALCULATION 11
7 CONNECTIONS 11
7.1 INPUT CONNECTIONS 11
7.1.1 BALANCED INPUTS 11
7.1.2 UNBALANCED INPUTS 12
7.2 CONNECTING LOUDSPEAKERS 12
8 OPERATION 13
8.1 OPERATION PRECAUTIONS 13
8.2 POWERING UP – SOFT START 14
8.3 INPUT ATTENUATORS 14
8.4 INDICATORS 14
9 PROTECTION FEATURES 14
9.1 OUTPUT LIMITER 14
9.2 THERMAL PROTECTION 15
9.3 VHF PROTECTION 15
9.4 SHORT CIRCUIT PROTECTION 15
9.5 AC MAINS VOLTAGE PROTECTION 15
9.6 DC PROTECTION 15
10 MAINTENANCE 16
10.1 TROUBLESHOOTING 16
11 WARRANTY 17
12 SPECIFICATIONS MA200Q 18
CONTENTS
<
>
PRINT
Martin Audio – MA200Q Amplifier
ENGLISH
2
2 APPROVALS
This equipment conforms to the requirements of the EMC directive 89/336/EEC, amended by
92/31/EEC and 93/68/EEC and the requirements of the Low Voltage Directive 73/23/EEC,
amended by 93/68/EEC.
Standard Applied EMC Emission EN55103-1, E3
EMC Immunity EN55103-2, E3, with S/N below 1% at normal operation level.
Electrical Safety EN60065, Class I
3 WARNINGS
3.1 Explanation of graphical symbols
The lightning symbol within a triangle is
intended to alert the user to the
presence of lethal voltages within the amplifier
that are of sufficient magnitude to constitute a
risk of electric shock to humans.
The exclamation mark within a triangle is
intended to alert the user to presence of
important operating and service instructions in
the literature accompanying the product.
3.2 WARNING
To reduce risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
3.3
CAUTION
To reduce the risk of fire or electric shock, do
not remove screws. There are no user-
serviceable parts inside this amplifier. Refer
servicing to qualified personnel only.
3.4 Important Safety Instructions
Before using your amplifier, please read the operating instructions and the safety suggestions.
1. Keep this manual for future reference.
2. Do not operate this amplifier if liquid ingress is suspected.
3. Do not stand water or any other liquid on, or near the amplifier.
4. Do not use this unit near water. Do not operate the amplifier if wet or standing in liquid.
5. Clean only with dry cloth.
6. Do not block the air intake or exhaust ports. Always install the unit in accordance with the
instructions.
7. Do not operate the amplifier on or near any source of heat, such as radiators, lighting dimmer
racks, or other apparatus that produces heat.
8. Always operate the amplifier with the chassis ground wire connected to the electrical safety earth.
Do not tamper with the electrical safety earth, it is provided for your safety. A grounding-type plug
is fitted; this has two pins and a third grounding prong. If the plug provided does not fit your mains
outlet, consult an electrician or a competent person to replace the fitted plug.
See p ag e 9, 6.3 for wiring colour code
!
!
CONTENTS
<
>
PRINT
