Sida 1/14
Martin Audio – WAVEFRONT PROFESSIONAL SERIES
CONTENTS (ENGLISH) Page No
1 INTRODUCTION 2
2 UNPACKING 2
3 OVERVIEW 2
3.1 W0.5 and WM0.5 2
3.2 W1 3
3.3 W2 3
3.4 W3 and W3P 3
3.5 WS2A 3
4 SAFETY FIRST 4
4.1 Tripod Mounting 4
4.2 Stacking 4
4.3 Rigging and Suspension 4
5 AMPLIFICATION 5
6 CONNECTIONS 6
7 CABLE LENGTHS 6
8 SYSTEM CONFIGURATIONS 7
9 WARRANTY 7
10 TECHNICAL SPECIFICATIONS 8
MARTIN AUDIO
LONDON
The Martin Experience
All material © 2007. Martin Audio Ltd. Subject to change without notice.
CONTENTS
<
>
PRINT
GUIDES
1 INTRODUCTION
Thank you for purchasing a Martin Audio Wavefront Professional Series
system. The Wavefront Professional Series is a range of powerful yet
compact loudspeakers designed to suit a variety of professional
applications. The trapezoid shape of the enclosures allows them to be
used singly or arrayed in multiples. Specific uses include live sound
reinforcement, theatre sound and audio-visual events.
2 UNPACKING
Each Martin Audio loudspeaker is built to the highest standard and
thoroughly inspected before it leaves the factory. After unpacking the
system, examine it carefully for any signs of transit damage and inform
your dealer if any such damage is found. It is suggested that you retain
the original packaging so that the system can be repacked at a future date
if necessary.
Please note that Martin Audio and its distributors cannot accept any
responsibility for damage to any returned product through the use of
non-approved packaging.
3 OVERVIEW
The Wavefront Professional Series consists of the W0.5 and WM0.5
miniature full-range systems, the W1, W2 and W3 compact full-range
systems and the WS2A sub-bass. For optimum performance it is
recommended that Wavefront Professional Series loudspeakers are used
with the WX3A System Controller or an appropriate digital controller such
as the Martin Audio DX1. Please refer to the controller user guide for
information on connections and limiter settings.
3.1 W0.5 and WM0.5
The W0.5 is a miniature high performance loudspeaker suited to a variety
of applications from sports bars to live sound infill. It is a passive two-way
system featuring an 8" (200mm) bass driver and a 1" (25mm) ferrofluid
cooled HF driver on a 70 x 50 degree horn.
The WM0.5 is a wedge monitor version of the W0.5, utilising the same
drive units and horn. In its wedge configuration, the horn of the WM0.5
exhibits a 50 x 70 degree dispersion pattern to increase the listening
window in the vertical plane. The base of the WM0.5 is provided with
threaded steel inserts for use with a tripod or for mounting upside down
close to a ceiling.
Martin Audio – WAVEFRONT PROFESSIONAL SERIES
ENGLISH
2
This equipment conforms to the requirements of the
EMC Directive 89/336/EEC, amended by 92/31/EEC
and 93/68/EEC and the requirements of the Low
Voltage Directive 73/23/EEC, amended by 93/68/EEC.
Standards Applied EMC Emission EN55103-1:1996
Immunity EN55103-2:1996
Electrical Safety EN60065:1993
All material © 2007. Martin Audio Ltd. Subject to change without notice.
CONTENTS
<
>
PRINT
GUIDES
