Sida 1/19
Owners Manual
MXL023/WQ & MXLO23/GQ
UK contact:
Helpline: +44 (0)1553 811000
Email: support@maxview.co.uk
Web: www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
9111450 Iss 1
VuQube II Q
Introduction
Thank you for purchasing this product, should you have any difficulty using your VuQube II Satellite System
please contact our friendly Customer Helpline on (01553) 811000. The VuQube II Satellite System is easily
configured to lock onto the appropriate satellites necessary to receive your favourite TV channels.
Please retain these instructions for future reference.
This pack includes:
• Antenna Unit
• Power Inserter
• 5m ‘F’ to ‘F’ Cable x 2
• 0.5m ‘F’ to ‘F’ Cable
• 2 x Velcro Control Box Mounting Pads
• Cigarette Adaptor 12V Power Supply
02
Record your purchase
Please fill in the details above once purchased.
This information will be required in the unlikely
event of a fault occurring with this system.
✴
This can be located at the bottom of the VuQube II near the F
connector ports below the handle (highlighted in blue on the image).
✴
SERIAL NUMBER:______________ PURCHASE DATE:_______________ __
VuQube II Roof Mount Pack - Available separately
If you wish to mount your VuQube II to your vehicle roof permanently
you will need to purchase our Roof Mount Pack
✴
. Order MXL023/FKIT
✴
PLEASE NOTE: If you mount your Vuqube II without using the
Maxview Roof Mount Pack your warranty will be void.
You will also need:
• TV & SKY™ Q Box
• Cable(s) to connect receiver to TV (e.g HDMI)
• Optional Cable Entry Product (see page 08)
Safety precautions
To avoid tripping over and injury always route cable carefully.
Maintenance
The VuQube II has been designed to be maintenance and trouble free. For optimum signal strength, keep the
cover clean from dirt, bugs, and other debris. Periodic washing of the top cover with mild soap and water is
recommended.
1. Always handle the antenna and VuQube II Power Inserter with care. Do not drop the antenna or VuQube II
Power Inserter. Avoid excessive shock or vibration to the antenna or VuQube II Power Inserter.
2. Use caution when carrying the antenna. Always carry the antenna by the handle.
3. Do not remove the cover of the antenna or VuQube II Power Inserter. Doing so is not recommended by the
manufacturer and will void the limited guarantee.
4. Do not stack the antenna or VuQube II Power Inserter on top of or below other electronic devices as this can
cause heat build-up or block the satellite signal from reaching the antenna.
5. Never power wash the antenna. Keep the enclosure clean from dirt, bugs, and other debris by hand washing
with mild soap and water.
DO NOT USE SOLVENTS TO CLEAN VUQUBE II. DO NOT DROP OR EXPOSE TO JARRING MOVEMENTS.
Please note
This product has been designed to work with SKY™ Q Boxes only and Maxview cannot guarantee operation with
any other Wideband Satellite Receiver. In very extreme rain fall and snowing conditions you may loose some TV &
Radio channels temporarily.
Terms & conditions
It is the responsibility of the end user to understand the contractual agreement between themselves and Sky™
& any limitations of equipment this may have. In no event shall Maxview be liable for any indirect, incidental, or
consequential damages pertaining to this article.
In no event shall Maxview be liable for any indirect, incidental, or consequential damages from the sale or use
of the product. This disclaimer applies both during and after the term of the guarantee. This guarantee gives you
specific legal rights, but does not affect your statutory rights. See page 10 further details.
03
1. Place the VuQube II on a stable surface with a clear view of the southern sky.
(With its built-in levelling feature, the VuQube II does not need to be level, but make sure it is stable to prevent
movement during operation.) Point the handle approximately to the north (this will speed up search time).
2. Make the connections as shown on the next page.
Set up for portable application
!
Satellite line of sight
IMPORTANT! HAND TIGHTEN COAX CONNECTIONS. DO NOT USE A WRENCH.
Do not allow the coax cable to become bent or kinked.
Do not leave the coax cable where it can be tripped on or run over by a vehicle.
IMPORTANT Do not block the antenna’s line of sight to satellites in the southern sky at any time.
