Sida 1/3

InstallationManual



 Type：GeneralTypeDINrailwithSinglePhase

（Series：DR‐45,DR‐75,DR‐120,DRP‐240,DRP‐480,DRP‐480S）



DR‐45‐5INPUT:100‐240VAC1.5A50/60HzOUTPUT:5V5A

DR‐45‐12 INPUT:100‐240VAC1.5A50/60HzOUTPUT:12V3.5A

DR‐45‐15 INPUT:100‐240VAC1.5A50/60HzOUTPUT:15V2.8A

DR‐45‐24 INPUT:100‐240VAC1.5A50/60HzOUTPUT:24V2A

DR‐75‐12 INPUT:100‐240VAC2A50/60HzOUTPUT:12V6.3A

DR‐75‐24 INPUT:100‐240VAC2A50/60HzOUTPUT:24V3.2A

DR‐75‐48 INPUT:100‐240VAC2A50/60HzOUTPUT:48V1.6A

DR‐120‐12 INPUT:100‐120/200‐240VAC3.3/2A50/60Hz OUTPUT:12V10A

DR‐120‐24 INPUT:100‐120/200‐240VAC3.3/2A50/60Hz OUTPUT:24V5A

DR‐120‐48 INPUT:100‐120/200‐240VAC3.3/2A50/60Hz OUTPUT:48V2.5A

DRP‐240‐24 INPUT:100‐240VAC3.5A50/60HzOUTPUT:24V10A

DRP‐240‐48 INPUT:100‐240VAC3.5A50/60HzOUTPUT:48V5A

DRP‐480‐24 INPUT:200‐240VAC4A50/60HzOUTPUT:24V20A

DRP‐480‐48 INPUT:200‐240VAC4A50/60HzOUTPUT:48V10A

DRP‐480S‐24 INPUT:100‐120/200‐240VAC11/4A50/60Hz OUTPUT:24V20A

DRP‐480S‐48 INPUT:100‐120/200‐240VAC11/4A50/60Hz OUTPUT:48V10A



 Introduction

TheDINrailpowersupplyisakindofexternalswitchingpowersupplyspecificallydesignedtofulfilthe

requirementsofDeutschesInstitutfürNormung(DIN),theGermanInstituteforStandardizationinEnglish.Asa

sortofDINrailpowersupplies,MeanWell’sDINrailpowersupplyseriescanbemountedon

aTS35StandardDIN

rail.

 Installation

（1）Alwaysallowgoodventilationclearances,5mmleftandright,40mmaboveand20mmbelow,aroundtheunit

inuse topreventitfromoverheating.Alsoa10‐15cmclearancemustbekeptwhentheadjacentdeviceisa

heatsource.

（2）Theappropriatemountingorientationfortheunit

is vertical,theinputterminalsatthebottomandoutputon

the top for DR‐75 and DR‐120, the input terminals on the right andoutput on the left for DR‐45, DRP‐240,

DRP‐480andDRP‐480S.Mountingorientationsotherthanthat,suchasupsidedown,horizontal,

ortable‐top

mounting,isnotallowed.





InstallationManual



（3）Usecopperwireonly,andrecommendedwiresareshownasbelow.

AWG 18 16 14 12 10

RatedCurrentof

Equipment(Amp)

6A 6‐10A 13‐16A 16‐25A 25‐32A

Cross‐sectionof

Lead(mm

)

0.75 1.00 1.5 2.5 4

Note:1.Currenteachwirecarriesshouldbede‐ratedto 80%ofthecurrentsuggested

abovewhenusing5ormorewiresconnectedtotheunit.

2.Themaximumallowablewirecross‐sectionalareafortheterminalofthe

DR‐45is12AWG/2.5mm

2

.

Makesurethatallstrands ofeach strandedwireentertheterminal connection and thescrewterminalsare

securely fixed to prevent poor contact. If the power supply possesses multi‐output terminals, please make

sureeachcontactisconnectedtowirestopreventtoomuchcurrentstressonasinglecontact.

（4）Usewiresthatcanwithstandtemperaturesofatleast80°CsuchasUL1007.

（5）Recommendedwir estrappinglengthis5mm(0.197”).

（6）Recommendedscrewdriveris4mm,slottedtype.

（7）Therecommendedtorquesettingforterminalsisshownasbelow.

Model I/P O/P

DR‐45 5kgf‐cm (4.4 Lb‐in) 5 kgf‐cm (4.4 Lb‐in)

DR‐75/120

DRP‐480/480S

10kgf‐cm(9Lb‐in) 10kgf‐cm(9Lb‐in)

（8）Suggested fuse and maximum number of the PSUs that can be connected to a  circuit breaker at 230V are

shownasbelow.

Model Fuse

Circuitbreaker

C16 D16

DR‐45

T2.5A/L250V 6 13

DR‐75

T2.5A/L250V 6 11

DR‐120

F4A/H250V 5 7

DRP‐240

F5A/L250V 4 8

DRP‐480S

T15A/H250V 3 3

（9）MountingInstruction：

Mountasshowninfigureonly,withinputterminalsdown,orelsesufficientcoolingwillnotbepossible.

AdmissibleDINrail：TS35/7.5orTS35/15

Forrailfastening：



（a）Tilttheunitslightlyrearwards.

（b）Fittheunitovertophatrail.

（c）Slideitdownward

untilithitsthestop.

（d）Pressagainstthebottomforlocki ng.

（e）Shaketheunitslightlytocheckthelockingaction.



"Click"
