Installation Manual

 Type：Open Frame (PCB) Type Switching Power Supply

(Families: PM, NFM, IRM, MPS, MPD, MPT, MPQ, RPS, RPD, RPT, PS, PD, PT, PQ, PPS, PPT, PPQ, ASP, PID,

L PS, LPP, EPS, EL P, E PP, M FM , M P M )

 Introduction

An open frame (PCB) type switching power supply is a power supply designed to be integrated or installed into a

system enclosure. Mean Well’s open frame (PCB) type power supplies include on board, general PCB, green PCB,

and medical PCB types

 Installation

（1）Before commencing any installation or maintenance work, please disconnect your system from the

utility. Ensure that it cannot be re-connected inadvertently!

（2）

At least 5mm insulation distance on the bottom of the unit should be kept and a Mylar film should be

added between the unit and the system. In addition, keep enough insulation distance, 10mm for

general type/15mm for medical type, around the unit.

（3）

Power supplies greater than 120W may require a forced air/fan for cooling. Please refer to

specifications to receive a minimum air intensity and air-flow direction.

（4）Allow good ventilation for the unit in use to prevent it from overheating. Also, a 10-15 cm clearance

must be kept when the adjacent device is a heat source.

（5）

Mounting orientations other than standard orientation or operate under high ambient temperature

may increase the internal component temperature and will require a de-rating in output current.

Please refer to the specification sheets to receive the optimum mounting position and information

about the de-rating curve.

（6）Recommended wires are shown as below.

AWG 18 16 14 12 10 8

Rated Current of

Equipment (Amp)

6A 6-10A 10-16A 16-25A 25-32A 32-40A

Cross-section of

Lead(mm

)

0.75 1.00 1.5 2.5 4 6

Note:Current each wire carries should be de-rated to 80% of the current

suggested above when using 5 or more wires connected to the unit.

（7）For other information about the products, please refer to www.meanwell.com for details.

 Warning / Caution !!

（1）Risk of electrical shock and energy hazard. All failure should be examined by a qualified technician.

Please do not try to fix the power supply by yourself!

（2）

Please do not install power supplies in places with high moisture or near the water.

（3）

Please do not install power supplies in places with high ambient temperature or near fire source.

Please refer to the specifications about the maximum ambient temperature limitations.

（4）

Output current and output wattage must not exceed the rated values on specifications.

（5）

The ground (FG) must be connected to earth ground.

（6）

All MW’s PSUs are designed in accordance with EMC regulations and the related test reports are

available by request. Since they are belong to component power supplies and will be installed inside

system enclosure, when they are integrated into a system, the EMC characteristics of the end

system must be re-verified again.
